Optomechanics
Tools of the trade - Vol 18 - 36188 Translating Post
Mounting Basics
â–Provides ±0.13 (3mm) of Translation
Optical Rails
â– #8-32 (M4) Stud 1/4"-20 (M6) TapAnti-backlash Spring Design
â–Lockable Design
Mirror Mounts Lens Mounts Filter MountsRotation
Lock RingPost Mounted FULLY COMPRESSED Adapters V-MountsApertures & Iris Diaphragms FULLY EXTENDED Lens Tubes
ITEM#METRIC ITEM#$£ ¥DESCRIPTIONCage Systems
TRT2TRT2/M$ 49.00£ 36.75 51,45¥ 8,330#8-32(M4) Stud 1/4-20 (M6)Tapped HoleUniversal Post Holder
â–Post Passes Through Base to Achieve Minimum Beam Height
â–Base Swivels 360°to “Pick Up” Most Convenient Mounting Holes
â–Magnets in Base Provide Holding Force Prior to Fasteningto Optical Table. Magnets hold the post holderallowing the base to rotate to “pick-up” mounting holes.
UPH3 Complete, Post Holder & Base Assembly UPH2 UPHA TRT2 Swivel Base rotates a full 360°to alloweasy pick-up of mounting holes. ITEM#*$£ ¥ LENGTH DESCRIPTION UPH1$26.50£19.88 27,83¥4,5051"1" High Universal Post Holder UPH1.5$27.00£20.25 28,35¥4,5901.5"1.5" High Universal Post Holder UPH2$28.00£21.00 29,40¥4,7602"2" High Universal Post Holder UPH3$29.00£21.75 30,45¥4,9303"3" High Universal Post Holder UPH4$31.00£23.25 32,55¥5,2704"4" High Universal Post HolderUPH6$33.50£25.12 35,18¥5,6956"6" High Universal Post Holder*Universal Design Metric and Imperial Compatible.
Swivel Base Adapter
Our new 360°swivel base adapter fits all standardPH-Series post holders with 1/4"-20 (M6)mounting holes (See previous page). The swiveldesign is ideal for applications that require a large number of components to be packed into a small area. Additionally, the swivel base will decrease thetime required to assemble an optical system. The TRT2 translating post has been designed to provide quick and stable heightadjustment of a mounted component within an optical setup. Utilizing a knurledcollet, centered on the post, the TRT2 can translate ±0.13" (3mm) from itsnominal position. Once the desired height is found, the TRT2 can be locked in place with a lock ring.
UPHA: ThisSwivel Base is Ideal for Building High Density Tabletop Optical Assemblies. ITEM#$£ ¥DESCRIPTION 360°SWIVEL UPHA*$19.50£14.62 20,48¥3,315Universal Post Holder Adapter*Universal Design Metric and Imperial Compatible.
