SMA Fiber Collimation Packages (con't)
r
Aspheric Collimator 8mm EFL
Collimation Packages
Aspheric Collimator 4.5mm EFL
SMA CONNECTOR
SMA CONNECTOR
Optical Switches
0.615" (15.6mm)
FIBER OPTIC CABLE
FIBER OPTIC CABLE
Rackbox Systems
5*
12mm-0.5 THREAD
11mm-0.5
THREAD
Connectors/ Termination Tools
012mm COMPATIBLE WITH AD12F MOUNTING ADAPTER
F230SMA ASSEMBLY
011.0mm DIAMETER
F230SMA ASSEMBLY
F240SMA ASSEMBLY
Single-Mode Fiber
Aspheric Collimator 15.29mm EFL
Aspheric Collimator 11mm EFL
Rare Earth Doped
1—0.715" (18.2mm) D
__L
"~r
11mm-0.5 THREAD
SMA CONNECTOR
Single-Mode: PM
SMA CONNECTOR
0.873"
(22.2mm)
FIBER OPTIC
CABLE
FIBER OPTIC CABLE
Photonic Crystal Fiber
11mm-0.5
THREAD
Multimode Fiber: Graded Index
F220SMA ASSEMBLY
F260SMA ASSEMBLY
011.0mm DIAMETER
F220SMA ASSEMBLY
011.0mm DIAMETER
F260SMA ASSEMBLY
Multimode Fiber: Step Index
SMA Connectorized Collimation Packages
ITEM#
$
£
€
„
AR COATING'
D2
e3
NAlens
F (mm)
F230SMA-A
$ 133.00
£ 99.75
€ 139,65
„22,610
400-600nm
0.9mm
0.045°
0.55
4.5
F230SMA-B
$ 133.00
£ 99.75
€ 139,65
„22,610
600-1050nm
0.9mm
0.051°
0.55
4.5
F230SMA-C
$ 133.00
£ 99.75
€ 139,65
„22,610
1050-1600nm
0.8mm
0.118°
0.55
4.5
F240SMA-A
$ 140.00
£ 98.00
€ 147,00
„ 23,520
400-600nm
1.6mm
0.025°
0.50
8.0
F240SMA-B
$ 140.00
£ 98.00
€ 147,00
„ 23,520
600-1050nm
1.6mm
0.029°
0.50
8.0
F240SMA-C
$ 140.00
£ 98.00
€ 147,00
„ 23,520
1050-1600nm
1.4mm
0.067°
0.50
8.0
F220SMA-A
$ 127.00
£ 95.25
€ 133,35
„21,590
400-600nm
2.2mm
0.018°
0.25
11.0
F220SMA-B
$ 127.00
£ 95.25
€ 133,35
„21,590
600-1050nm
2.2mm
0.021°
0.25
11.0
F220SMA-C
$ 127.00
£ 95.25
€ 133,35
„21,590
1050-1600nm
2.0mm
0.048°
0.25
11.0
F260SMA-A
$ 123.00
£ 86.00
€ 129,00
„ 20,640
400-600nm
3.0mm
0.013°
0.16
15.3
F260SMA-B
$ 123.00
£ 86.00
€ 129,00
„ 20,640
600-1050nm
3.1mm
0.015°
0.16
15.3
F260SMA-C
$ 123.00
£ 86.00
€ 129,00
„ 20,640
1050-1600nm
2.7mm
0.035°
0.16
15.3
NOTES:
1) See data on AR Coatings on www.thorlabs.com
2) Measured 1/e2 diameter @ 1 focal length from lens; fibers: 460HP (-A), SM600 (-B), SMF-28 (-C & -1550)
3) Calculated beam full angle of divergence; fibers: 460HP (-A), SM600 (-B), SMF-28 (-C & -1550)
COATING
ALIGNED AT
-A
543nm
-B
633nm
-C
1310nm
Standard SM05 Thread (0.535-40)
Fixed Focus Lens Adapter
Allows Aspheric Cells (09mm) to be Mounted with Collimation Packages (011mm) Allows Collimation Packages to be Integrated to Components with SM05 Thread (with or without an aspheric lens) Mounted Aspheric Lens Oriented to Minimize Aberrations.
M9-0.5 Thread Accepts Standard 9mm Lens Cells
Fiber Collimator & Aspheric Lens Sold Separately
ITEM#
$
£
€
„
DESCRIPTION
AD1109F
$ 28.00
£ 21.00
€ 29,40
„ 4,760
Focus Lens Adapter
C
ollimation Package Holders
Thorlabs' 011mm, 012mm & 015mm
Collimation Packages may be integrated with our 3-
axis translation stages (see page 290) using the HCS011 (011mm Collimators) & HCS015 (015mm Collimators) mounts.
Nylon tipped set screws secure the collimation package without marring the housing.
HCS011
HCS015
ITEM#
$
£
€
„
DESCRIPTION
HCS011*
$ 40.00
£ 30.00
€ 42,00
„ 6,800
011mm Collimation Mount
HCS012*
$ 40.00
£ 30.00
€ 42,00
„ 6,800
012mm Collimation Mount
HCS015*
$ 35.00
£ 26.25
€ 36,75
„ 5,950
015mm Collimation Mount
Microscope Objectives, see page 201.
•Universal Design
THOR ^
Sales: 973-579-7227
835
