Polarization Tools

Tools of the trade - Vol 18 - 36188 PMD / PDLMeasurement Systems...Page 2 of 4

Polarization Measurement&Control General PMD Measurements
PMD/PDLMeasurements PMD Measurements on Narrow Bandwidth Components

PMD5000FIN

ThePMD5000FIN is recommended for general polarization modedispersion measurements. Especially PMD and PDL analysis of fibers and broadband components can be performed with this model. This includes the PMD measurement of passive components (couplers, isolators) and active components (EDFAs and PDFAs). Narrow bandwidth components such as optical filters, Bragg gratings, andOADM, are considerably more challenging to characterize. For narrow bandcomponent manufacturing it is important to assess the PDL in the “wings” of the pass-band (typically around 20dB) to determine if the component meets the isolation requirement between adjacent channels. The PMD5000HDR facilitates this assessment and can increase productionyield. A main advantage of this system is the high dynamic power range ofthe polarimeter. This affords an optimal characterization of the edges of the narrow bandwidth element.
Polarization â–  DGD Meter with a Range of 0.001ps to 400ps
Accessories â–  Repeatability:
1 <0.01ps
â–  Maximum Insertion Loss of DUT:
2 30dB
â–  Typical Measurement Time for 1 (100) DataPoints: 0.5s (50s)
â–  Jones Matrix PMD Measurement Method
â–  Ideal for PMD & PDL on Optical Fiber
â–  Includes a Deterministic Polarization Controller DPC5500 & Fast In-Line Polarimeter IPM5300
â–  Integrated Tunable Laser Source ECL5000D (PMD5000FIN-1)
1) For PMD <0.3ps2) At Input Power ≥ 1mW

PMD5000HDR

â–  DGD Meter with a Range of 0.001ps to 400ps
â–  Repeatability:
1 <0.01ps
â–  Maximum Insertion Loss of DUT:
2 60dB
â–  Typical Measurement Time:1 Data Point in SYSTEM CONFIGURATIONS - SEE PAGE 817Thorlabs is recognized throughout the photonics community forproviding novel polarization measurement and control solutions. Our team of polarization experts has, as can be seen from ourbroad selection of related products, tackled many challengingmeasurement and control problems in this specialized field. The selection guide shown on page 817 describes the various systems offered for a broad array of PMD & PDL measurements. 0.5s100 Data Points in 50s
â–  Jones Matrix PMD Measurement Method
â–  Ideal for PMD & PDL on Narrow BandwidthComponents
â–  Includes a Deterministic Polarization Controller DPC5500 & High Dynamic Range PolarimeterPAX5720IR3
â–  Integrated Tunable Laser Source ECL5000D(PMD5000HDR-1)
1) For PMD <0.3ps2) At Input Power ≥ 1mW Polarization Analysis

System Capabilities

PMD Measurement
â–  Dynamic Polarization Measurements in Real Time
â–  PMD Measurements based on the Jones MatrixEigenanalysis
â–  Fiber or Free Space Input (depending on PolarimeterModule)
â–  PMD Measurement of installed Fibers according to theJones-Matrix Method
â–  Long Term Observation of Polarization Effects
â–  Polarimeter Measurements with Azimuth & EllipticityAngle Accuracy <0.25º
â–  PMD Measurement in Accordance with ITU-T G.650
â–  DGD Measurement Range 0.001 to 400ps with 0.01psReproducibility
â–  Large Dynamic Range: -60dBm to +10dBm (PAX5720IR3)
â–  Fast Measurement Speed: 1Msample/s (IPM5300)
â–  High Resolution PMD Measurement of Narrow-Band Components
â–  Range: PAX5720IR3: 1350 to 1700nmIPM5300:1510 to 1640nm
â–  Mean and RMS Values of PMD, plus 2nd Order PMD Coefficient
â–  Long Term PMD Measurement Polarization Control
â–  Measures the Principal States of Polarization as a Function of Wavelength
â–  Deterministic Polarization Control and Locking
â–  Accurate and precise SOP Tracing
â–  Optional Use of 3rd Party Tunable Lasers
â–  SOP Scrambling
â–  Integrated Tunable Laser Source
â–  Wavelength Range: 1510 to 1640nm PDL Measurement
â–  Dynamic Range: 35dB (-20dBm to +15dBm)
â–  PDL Measurements based on Jones Matrix Eigenanalysis
â–  Fast SOP Adjustments: <150µs Typical
â–  PDL Measurement in the Range of 0 to 50dB with
â–  â–  Measurement of the Wavelength and Time Dependency of the PMD and PDL Changes Extinction Ratio Measurement of PM Fiber
â–  Measurement Range 0 to 50dB Sales: 973-579-7227
815
