Polarization Measurement & Control Selection Guide

Pages 804-824

PAX5700 Series Polarimeter

The PAX5700 series polarimeter system is a flexible and powerfulpolarization analysis system based on our modular TXP5000 platform. This polarimeter system was designed for different applications ranging from classic polarization measurements to complex tasks like evaluating optical components with the Jones or Mueller matrix algorithm. It is also well suited for determining the Extinction Ratio (ER) of polarization maintaining fibers (PMF) and alignment of PMF to laser modules.

See Pages 806-808

DPC5500 Fast Inline Deterministic Polarimeter

The DPC5500, an in-line deterministic polarization controller for theTXP5000 systems (see page 416), combines deterministic state of polarization control, high speed, low loss and high accuracy in a unique and unprecedented way.It is a versatile polarization control solution that may be utilized in many applications, ranging from R&D and manufacturing to industrial applications.

See Page 809

IPM5300 Fast In-Line Polarimeter

The IPM5300 fiber-optic polarimeter module for the TXP5000 platformenables high speed measurements of the state of polarization (SOP). The in-line fiber design provides an insertion loss of less than 0.5dB, a dynamic range of -30 to +15dBm, and an accuracy of ±0.25°on the Poincaré sphere with a sampling rate of 1MHz.

See Pages 810-811

PL100 State of Polarization Locker (SOP)

The PL100 series SOP Locker is an in-line deterministic polarizationcontroller. This bench-top device utilizes the IPM and DPC technology (See page 809) and offers deterministic state of polarization control, high speed, low loss, and high accuracy. It is a versatile polarization control solution that may be utilized in many applications where a stable output polarization is required independent from the input polarization.

See Page 812

Manual Polarization Controllers

If your application includes single mode fiber and requires linearlypolarized light, FPC030 Polarization Controllers can easily be implemented to convert elliptically polarized light from single mode fiber into linearly polarized light.

See Page 813

PMD/PDL Measurements

Polarization Measurement Systems

The PMD5000 system has been designed to analyze highly accuratepolarization related effects in fiber optic systems. It provides extensivemeasurement and analysis of Polarization Mode Dispersion (PMD), and is capable of determining Polarization Dependent Loss (PDL) and Gain (PDG).

See Pages 814-817
