StableTop™ 450 SeriesNon-Magnetic Optical Tables StableTop™ 450 Series

BreadboardsBreadboard The ultimate table for the most demanding research applications, Thorlabs Non-Magnetic StableTop™ 450 tables employ maximum tunedand broadband damping, producing an extremely low deflection coefficient.Triple plate double honeycomb StableTop™ technology produces the most rigidcomposite tables in the industry. The outer skins are matched with the internal plate to minimize bowing due to thermal variations and cycling and to ensure the flatness of the table is maintained. Mounting holes are sealed making the cleanupof spills easy.
Supports â–  Optical Tables Non-Magnetic 304L Stainless Steel Topand Bottom Plate
â–  2 Table Supports Flatness: ±0.1mm (±0.004") Over any 1m
â–  Construction: Triple Plate, Double Honeycomb Aluminum Core
Non-Magnetic â–  Damping: Maximum Proprietary Tuned and Broadband Damping
â–  Dynamic Deflection Coefficient:<0.5 x 10
-3 â–  Brass Sealing Cups 316L StainlessSteel Avaliableupon Request Optical Table NTR11109 is shown with self-leveling isolation system NTS503, shown on page 67. For our full line of vibration isolation systems,see pages 67-68.
NTR11109 US Patent 5402734 10 -6 10 -7 StableTop 450 SeriesIdeal Rigid Body 10 -8

Non-Magnetic StableTop™450 Series

-9 non-magnetic 304L stainless steel top and bottom skin Compliance (in./lb) 10 (same material prevents bowingwith temperature change) Table Cross Section
brass sealing cups triple layer (ensure thermal conductivity and greater rigidity) (creates shorter elements between top and bottom skin therefore increasing stiffness) 10 -10 10 -11 101001000Frequency (Hertz) Typical Compliance curve for the StableTop™450 Series I - measured at table corner

NON-MAGNETICULTRA-STABLE

aluminum side walls aluminum honeycomb hot press bonded (provides greater stiffness) (provides a high strength to weight ratio) (entire table bonded under high pressure and temperature providing greater rigidity and stiffness)

Tools of the trade - Vol 18 - 36188 GREAT PRICE!

â–  Intermediate Core: Brass Sealing CupAluminum Honeycomb Structure, 13mm(0.5") Thick

SPECIFICATIONS

â–  Maximum Screw Length: 16mm (5/8")
â–  Table thickness: 8.3" (210mm)
â–  Mounting Hole Pattern:
â–  Dynamic Deflection Coefficient (Max):
â–  Flatness: ±0.1mm (±0.004") Over any 1m
2 • Metric: M6 on 25mm Centers• Imperial: 1/4"-20 on 1" Centers <1.3 x 10
-3 *
â–  Construction: Triple Plate, DoubleHoneycomb Core
â–  â–  Edge to First Hole Center: Relative Table Motion (Max):
-9 <0.10nm(4 x 10 in.)*
â–  Top and Bottom plates: • Metric: 50mm on all Sides• Imperial Models 4.1' Width: 2.0" on Ends& 2.6" on Sides• Imperial Models 4.9' Width: 2.0" on Ends& 2.5" on Sides
â–  Deflection Under Load:
-5 113kg (250 lbs):<1.5µm (5.9 x 10 • Matched Materials for Athermalized Design• Non-Magnetic 304L Stainless Steel,5mm Thick in.)*
*Measured on a 4.1 x 8 ft. x 8.3 in. table with isolatortransmissibility T<0.01 above 10 Hz, environmental vibrations PSD <10 -9 2 â–  Main Core: High-density Plated Aluminum Honeycomb
g /Hz. Non-Magnetic Optical Tables, 1/4"–20 Stocked for Immediate Delivery
ITEM#$£ ¥DIMENSIONS (L xW xH) NTR11109$9,173.20 £5,396.00 8.094,00 ¥ 1,510,8808' x 4.1' x 8.3"NTR11114$11,789.50 £6,935.00 10.402,50 ¥ 1,941,80010' x 4.9' x 8.3" Non-Magnetic Optical Tables, M6 Metric Stocked for Immediate Delivery
ITEM#$£ ¥DIMENSIONS (L xW xH) NTR51509$8,887.60 £5,228.00 7.842,00 ¥ 1,463,8402500 x 1250 x 210mmNTR51514$12,141.40 £7,142.00 10.713,00 ¥ 1,999,7603000 x 1500 x 210mm Please contact your local sales office for a quotation including shipping. 66 Sales: 973-579-7227
