Tools of the trade - Vol 18 - 36188 StableTop™ 350 Series StableTop™ 350 Series Non-Magnetic Optical Tables

ScienceDesk™ Thorlabs Non-Magnetic StableTop
TM 350 tables offer a tuned and broadband enhanced damping system, resulting in increased dynamicstiffness when compared to the Performance series tables. Triple-plate double-honeycomb Non-Magnetic StableTop™ technology produces themost rigid composite tables in the industry. The outer skins are matched with the internal plate to minimize bowing due to thermal variations and cycling and to ensure the flatnessof the table is maintained. Mounting holes are sealed with brass sealing cups making thecleanup of spills easy.
BreadboardsBreadboard Supports â–  Non-Magnetic 304L Stainless Steel Topand Bottom Plate
Optical Tables â–  Flatness: ±0.1mm (±0.004")Over any 1m
2 Table Supports â–  Construction: Triple Plate, DoubleHoneycomb Aluminum Core
Non-Magnetic â–  Damping: Proprietary Tuned andBroadband Damping
â–  Dynamic Deflection Coefficient:<0.7 x 10
-3 â–  Mounting Holes are Sealed with BrassCups for Easy Cleanup 316L Stainless Steel Avaliable upon Request Optical Table NTQ11109 is shown with self-leveling isolation system NTS503, shown on page 67. For our full line of vibration isolation systems, see pages 67-68.
NTQ11109 US Patent 5402734 10 -3

Non-Magnetic StableTop™350 Series

10 -4 StableTop 350 SeriesIdeal Rigid Body Table Cross Section
10 -5 non-magnetic 304L stainless steel top and bottom skin -6 Compliance (in./lb) 10 (same material prevents bowingwith temperature change) brass sealing cups triple layer (ensure thermal conductivity and greater rigidity) (creates shorter elements between top and bottom skin therefore increasing stiffness) 10 -7 10 -8 101001000Frequency (Hertz) Typical Compliance curve for the StableTop™350 Series I Table - measured at table corner
aluminum side walls aluminum honeycomb hot press bonded (provides greater stiffness) (provides a high strength to weight ratio) (entire table bonded under high pressure and temperature providing greater rigidity and stiffness)

NON-MAGNETIC

TRIPLE-PLATE

DOUBLEHONEYCOMB

DESIGN

SPECIFICATIONS

â–  Maximum Screw Length: 16mm (5/8")
â–  Table thickness: 8.3" (210mm)
â–  Mounting Hole Pattern:
â–  Intermediate Core: Brass Sealing CupHoneycomb Structure, 13mm (0.5") Thick
â–  Flatness: ±0.1mm (±0.004") Over any 1m
2 • Metric: M6 on 25mm Centers• Imperial: 1/4"-20 on 1" Centers
â–  â–  Construction: Triple Plate, DoubleHoneycomb Core Dynamic Deflection Coefficient
-3 (Max):<0.7 x 10
â–  Edge to first hole center: *
â–  â–  Top and Bottom plates: • Metric: 50mm on all Sides• Imperial Models 4.1' Width: 2.0" on Ends& 2.6" on Sides• Imperial Models 4.9' Width: 2.0" on Ends& 2.5" on Sides Relative Table Motion
-9 (Max): <0.14nm(5.5 x 10 in.)* • Matched Materials for Athermalized Design• Non-Magnetic 304L Stainless Steel,5mm Thick
â–  Deflection Under Load: 113kg (250 lbs): <1.5µm (5.9 x 10
-5 in.)*
*Measured on a 4.1 x 8 ft. x 8.3 in. table with isolatortransmissibility T<0.01 above 10 Hz, environmental vibrationsPSD <10 â–  Main Core: High-density Non-MagneticPlated Aluminum Honeycomb
-9 g 2 /Hz. Non-Magnetic Optical Tables, 1/4"–20 - Stocked for Immediate Delivery
ITEM#$£ ¥DIMENSIONS (L xW xH) NTQ11109$7,597.30 £4,469.00 6.703,50 ¥ 1,251,320 8' x 4.1' x 8.3"NTQ11114$10,189.80 £5,994.00 8.991,00 ¥ 1,678,32010' x 4.9' x 8.3" Non-Magnetic Optical Tables, M6 Metric – Stocked for Immediate Delivery
ITEM#$£ ¥DIMENSIONS (L xW xH) NTQ51509$7,597.30 £4,469.00 6.703,50 ¥ 1,251,320 2500 x 1250 x 210mmNTQ51514$10,189.80 £5,994.00 8.991,00 ¥ 1,678,320 3000 x 1500 x 210mm Please contact your local sales office for a quotation including shipping. Sales: 973-579-7227
