Non-Magnetic Optical Breadboards – 2.4" (60mm) Thick

ScienceDesk™

Thorlabs Non-Magnetic optical breadboards provide high performance at an economical price.These all non-magnetic steel breadboards are also an ideal laboratory platform for optical and laser experiments. The breadboards feature:

BreadboardsBreadboard Supports

â–

Minimal Deflection Under Load

Optical Tables

â–

Aluminium Honeycomb Core andInternal Damping Provide Both Staticand Dynamic Rigidity

Table Supports

â–

Non-Magnetic 304L Stainless Steel Topand Bottom Plate

Non-Magnetic

â–

Excellent Surface Finish, Achieved by Using Thermally Matched Materials

Specifications

â–

Bottom Plate:

â–

Flatness: Non-Magnetic 304L StainlessSteel, 5mm (3/16") Thick

2

±0.13mm (0.005") Over any0.3m Area

â–

Thickness: 2.4" (60mm)

â–

Sides: Black Laminated Aluminum

â–

Construction: Double-plate, AluminumHoneycomb-core, Athermalized Design

â–

Mounting Holes: • Imperial: 1â�„4"-20 on 1" Centers• Metric: M6 on 25mm Centers 316L Stainless SteelAvaliable upon Request

â–

Damping: Nominal

â–

Core: High-density AluminumHoneycomb

â–

Edge of Top Plate to First Hole: • Imperial: 2"• Metric: 50mm

â–

Maximum Screw Length: 16mm (5/8")

â–

Top plate: Non-Magnetic 304L StainlessSteel, 5mm (3/16") Thick, Brush Finished Non-Magnetic Breadboards, 2.4" Thick - Imperial – Stocked for Immediate Delivery

ITEM#$£ ¥DIMENSIONS NBH11110$1,256.30 £739.00 1.108,50¥ 206,9202.5' x 2.5' x 2.4" NBH11106$1,215.50 £715.00 1.072,50¥ 200,2003' x 2' x 2.4" NBH11111$1,377.00 £810.00 1.215,00¥ 226,8003' x 2.5' x 2.4" NBH11114$1,533.40 £902.00 1.353,00¥ 252,5603' x 3' x 2.4" NBH11112$1,655.80 £974.00 1.461,00¥ 272,7204' x 2.5' x 2.4"NBH11115$1,883.60 £1,108.00 1.662,00¥ 310,2404' x 3' x 2.4"
Please contact your local sales office for a quotation including shipping. Please contact your local sales office for a quotation including shipping.

Non-Magnetic Breadboards, 60mm Thick - Metric – Stocked for Immediate Delivery

ITEM#$£ ¥DIMENSIONS NBH51510$1,256.30 £739.00 1.108,50 ¥ 206,920750 x 750 x 60mm NBH51506$1,215.50 £715.00 1.072,50¥ 200,200900 x 600 x 60mm NBH51511$1,377.00 £810.00 1.215,00 ¥ 226,800900 x 750 x 60mm NBH51514$1,533.40 £902.00 1.353,00 ¥ 252,560900 x 900 x 60mm NBH51512$1,655.80 £974.00 1.461,00 ¥ 272,7201200 x 750 x 60mmNBH51515$1,883.60 £1,108.00 1.662,00 ¥ 310,2401200 x 900 x 60mm

Tools of the trade - Vol 18 - 36188 We help you

NanoMax™ Series Systems

For applications requiring theresolution, stability and adaptability, the NanoMax™ series of highly stable flexure based translation stages offers the ideal solution.

Precision Motion Controlfor basic research,industrialR&D and highprecision manufacturing... See Pages274-283
