Tools of the trade - Vol 18 - 36188 Mounted Achromatic Lens Kit

Kits, Mechanical Kits, Lenses â–  Contains our Ø1" Achromatic Doublets
â–  Labeled (Laser Engraved) for EasyIdentification

10% SAVINGS OVERBUYING THEINDIVIDUAL LENSES

Kits, Filters â–  Threaded with Thorlabs standard SM1 Lens Mounts (1.035-40)
Kits, Screws â–  Protective Case for Easy Storage These achromatic doublet lens kits contain our Ø1" achromaticdoublets mounted in engraved SM1 cells. These kits are ideal forexperimentors who need to have access to a variety of lenses all atonce to quickly optimize their systems.

Specifications

â–  Each Kit Contains Focal Lengths: f=30, 35, 40, 45,50, 60, 75, 100, 150, 200, 250, 300, 400 & 500mm
â–  -A1: AR Coated 400-700nm
â–  -B: AR Coated 650-1050nm
â–  -C: AR Coated 1050-1620nm Includes: f=30, 35, 40, 45, 50, 60, 75, 100, 150, 200, 250, 300, 400 & 500mm (All mounted in engraved Ø1" cells)

Visible Achromatic Doublets Near IR Achromatic Doublets Telecomm Achromatic Doublets

â–  Design Wavelength for Coating A1: 486.1nm, 587.6nm, & 656.3nm
â–  Design Wavelength for Coating B:
â–  Design Wavelength for Coating C: 706.5nm, 855nm, & 1015nm 1016nm, 1330nm, & 1550nm
â–  Dia. Tolerance: +0.00/-0.10mm
â–  Diameter Tolerance:
â–  Diameter Tolerance:
â–  Focal Length Tolerance: ±1% +0.00/-0.10mm +0.00/-0.10mm
â–  Scratch/Dig: 40/20
â–  Focal Length Tolerance: ±1%
â–  Focal Length Tolerance: ±1%
■ Centration: ≤ 3 arcmin.
â–  Scratch/Dig: 40/20
â–  Scratch/Dig: 40/20
â–  Clear Aperture: >90% of Dia.
■ Centration: ≤ 3 arcmin.
■ Centration: ≤ 3 arcmin.
â–  Coating: Ravg<0.5% from400-700nm (A1 coating range)
â–  Clear Aperture: >90% of Dia.
â–  Clear Aperture: >90% of Dia. -40°C to +85°C
â–  Coating: Ravg<0.5% from650-1050nm (B coating range)
â–  Coating: Ravg<0.5% from1050-1620nm (C coating range)
â–  Operating Temperature: -40°C to +85°C
â–  Operating Temperature:
â–  Operating Temperature: -40°C to +85°C
A1 Broadband Antireflection Coating (400-700nm) B Broadband Antireflection Coating (650-1050nm) % Reflection % Reflection 0123 350012345 450550650750 60070080090010001100 Wavelength (nm) Wavelength (nm) C Broadband Antireflection Coating (1050-1620nm) % Reflection 0123 Wavelength (nm)100011001200130014001500160017001800 ITEM #$£ ¥DESCRIPTION LSB08-A1$1,191.00£893.00 1.250,00¥202,490Visible Ø1" Achromatic Lens Kit (400-700nm) LSB08-B$1,360.00£1,020.00 1.430,00¥231,336Near IR Ø1" Achromatic Lens Kit (650-1050nm)LSB08-C$1,432.00£1,074.00 1.505,00¥243,432Telecom Ø1" Achromatic Lens Kit (1050-1620nm) Sales: 973-579-7227
