Tables & Breadboards

Tools of the trade - Vol 18 - 36188 Optical Table Support Systems

ScienceDesk™ BreadboardsBreadboard Supports Optical Tables

PTR12115

Table Supports Non-Magnetic

Optical Tabletop PTR12115 isshown with self-leveling isolation system PTS502, shown on page 58. For our full line of vibrationisolation systems (Active, Passiveand Rigid) see pages 58-62. Vibration isolators prevent motion and vibration from disturbingcomponents mounted on an optical table or breadboard. The bestisolator for an application depends upon experiment sensitivity, tabletop weight, and environmental vibration (noise).We recommend that you consider both immediate and futureneeds when choosing an isolator system. The chart below and the table discussion should help you select an optical table systemthat will suit your application and working environments. Specific isolator performance is provided on the following pages.If you should need further assistance, our application engineersare available to help you. Call us at 973-579-7227 and just ask for technical support. Isolator System Feature Comparison

Rigid Nonisolating Pump & Go™ Passive Vibration IsolatorsSuperDamp™ Self-Leveling FeatureSupports
StandardHeavy Duty Vibration Isolators Automatic Self-Leveling ✔ Manual Leveling ✔✔✔ Dual-ChamberDamped Pneumatic ✔ Spring Trifilar Suspension System ✔ Magnetic Sensor Coupling ✔ 3-Way Precision Valving ✔ NonresonantDesign ✔✔✔

Expanding

â–

6 Pin IEEE 1394 Interface

â–

640 x 480 or 1024 x 768 pixelResolution with 7µm Pixel Size

The Line

â–

24-Bit Color and B&W Versions

â–

Comes in with SM1 Thread and Cage MountingOptions

â–

Imaging LensesMatched to Our CCDCameras

â–

ImageAcquisitionSoftware

â–

Manual Iris & Focus

â–

Compact to Take Upthe Minimum Amountof Room on Your Optical Table

â–

8-bit A/DCCD

â–

External Trigger Sales: 973-579-7227
