Tools of the trade - Vol 18 - 36188 50:50 Broadband Plate Beamsplitters

Optical Systems PPLN Devices

Specifications

<15% over entirewavelength range

â–

Material: BK7or UV Fused Silica

â–

Splitter Ratio Tolerance: •

Spherical Singlets

• |Ts–Tp|<15% and|Rs–Rp|<15%

â–

Flatness: λ /10 @ 635nm Overthe Clear Aperture

Multi-element Lenses

â–

Wedge: 30±10 arcmin.

Cylindrical Lenses

â–

Diameter Tolerance:

â–

Coating on Surface 1: +0.0/–0.2mm Beamsplitter Coatingfor 45°Incidence

Aspheric Lenses

â–

Center Thickness Tolerance: ±0.4mm

â–

Coating on Surface 2:

Mirrors

See description

â–

Wavelength Range: Broadband AR Coating R<0.5%within Wavelength Range

Windows & Diffusers

â–

Durability: MIL-M-13508C,MIL-C-675C, MIL-C-14806 These non-polarizing beamsplitters use the samecoatings as our non-polarizing beamsplittingcubes. A slight wedge of 30 arcmin. has been added to eliminate interference fringes. The front surface is rotated with the broadband beamsplitter coating while the back surface has a broadband AR coating (R<0.5%) to eliminate ghosting.

â–

Clear Aperture: >90%of Central Diameter

Prisms

â–

Surface Quality: 20/10 Scratch-Dig

Gratings Diffractive Optics Polarization Optics

â–

Available in Ø1/2" (12.7mm), Ø1"(25.4mm) & Ø2" (50.8mm)

Beamsplitters

â–

Polarization Independent

Filters & Attenuators

â–

400-700nm, 700-1100nm & 1200-1600nm Versions for 45°Incidence

Gas Cells

â–

0.5°Wedge to Eliminate Interference Fringes

â–

AR Coated to Eliminate Ghosting 50:50 Split Ratio See graph on facing page There are three main types of beamsplitters: Pellicle, Cube andPlate. Each type has distinct advantages and disadvantages. Plate Beamsplitters - These are the most cost effective of all thebeamsplitter types. However, dispersion, ghosting and shifting ofthe beam may all be an issue in certain applications. These are thebest choice for a general purpose beamsplitter.See page 682-684 for Pellicle & Cube Beamsplitter details. 50:50 Splitting Ratio and AR Coated Back

ITEM#DIAMETERCOATINGMATERIAL$£ ¥T
1 SUGGESTED MOUNT BSW011/2” (12.7mm)400-700nmBK7$65.00£48.75 68,25¥11,0503mmLMR05 BSW021/2” (12.7mm)700-1100nmBK7$65.00£48.75 68,25¥11,0503mmLMR05 BSW031/2” (12.7mm)1200-1600nmBK7$65.00£48.75 68,25¥11,0503mmLMR05 BSW041/2” (12.7mm)400-700nmUV Fused Silica$71.00£53.25 74,55¥12,0703mmLMR05 BSW051/2” (12.7mm)700-1100nmUV Fused Silica$71.00£53.25 74,55¥12,0703mmLMR05 BSW061/2” (12.7mm)1200-1600nmUV Fused Silica$71.00£53.25 74,55¥12,0703mmLMR05 BSW071” (25.4mm)400-700nmBK7$91.00£68.25 95,55¥15,4705mmLMR1 BSW081” (25.4mm)700-1100nmBK7$91.00£68.25 95,55¥15,4705mmLMR1 BSW091” (25.4mm)1200-1600nmBK7$91.00£68.25 95,55¥15,4705mmLMR1 BSW101” (25.4mm)400-700nmUV Fused Silica$97.00£72.75 101,85¥16,4905mmLMR1 BSW111” (25.4mm)700-1100nmUV Fused Silica$97.00£72.75 101,85¥16,4905mmLMR1 BSW121” (25.4mm)1200-1600nmUV Fused Silica$97.00£72.75 101,85¥16,4905mmLMR1 BSW132” (50.8mm)400-700nmBK7$143.00£107.25 150,15¥24,3108mmLMR2 BSW142” (50.8mm)700-1100nmBK7$143.00£107.25 150,15¥24,3108mmLMR2 BSW152” (50.8mm)1200-1600nmBK7$143.00£107.25 150,15¥24,3108mmLMR2 BSW162” (50.8mm)400-700nmUV Fused Silica$152.80£114.60 160,44¥25,9768mmLMR2 BSW172” (50.8mm)700-1100nmUV Fused Silica$152.80£114.60 160,44¥25,9768mmLMR2BSW182” (50.8mm)1200-1600nmUV Fused Silica$152.80£114.60 160,44¥25,9768mmLMR2
1 Maximum edge thickness

Sales: 973-579-7227

685
