Tables & Breadboards

Siobloi'oo™¹ 450

Optical Tables

StableTop™ 450 Series II optical tables feature the same damping, materials and design techniques as the Series I range, but offer increased stiffness when compared to Series I models due to the increased thickness (12.2" (310mm) compared to 8.3" (210mm) thick). Choose a Series II table if your application would benefit from reduced compliance at a given frequency.

All Thorlabs tabletops offer the highest levels of surface flatness available, high dynamic stiffness and low relative tabletop motion, making them the obvious choice for any demanding scientific application

Breadboards

Breadboard Supports

Optical Tables

Table Supports

Non-Magnetic

PTR12113

Optical Table PTR12113 is shown with self-leveling isolation system PTS502, shown on page 58. For our full line of vibration isolation systems (Active, Passive and Rigid) see pages 56-62.

Legs sold separately.

US Patent 5402734

StableTop 450

Series II - for the most demanding research applications. The ultimate in performance & quality.

■ Flatness: ±0.01mm (±0.004") over any 1m²

■ Construction: Triple Plate, Double Honeycomb Core

■ Damping: Maximum Proprietary Tuned and Broadband Damping

■ Dynamic Deflection Coefficient: < 0.5 x 10^-3

Various supports available, see pages 56-62.


Optical Tables: 1/4"-20 - Stocked for Immediate Delivery
ITEM#	$	£	€	¥	DIMENSIONS (L x W x H)
PTR12109	$ 5,266.60	£ 3,098.00	€ 4.647,00	¥ 867,440	8' x 4.1' x 12.2"
PTR12113	$ 6,058.80	£ 3,564.00	€ 5.346,00	¥ 997,920	8' x 4.9' x 12.2"
PTR12110	$ 6,123.40	£ 3,602.00	€ 5.403,00	¥ 1,008,560	10 'x 4.1' x 12.2"
PTR12114	$ 6,730.30	£ 3,959.00	€ 5.938,50	¥ 1,108,520	10' x 4.9' x 12.2"
PTR12115	$ 8,443.90	£ 4,967.00	€ 7.450,50	¥ 1,390,760	12' x 4.9' x 12.2"
Optical Tables: 1/4"-20 ... Call for Lead Time
ITEM#	$	£	€	¥	DIMENSIONS (L x W x H)
PTR12104	$ 3,522.40	£ 2,072.00	€ 3.108,00	¥ 580,160	6' x 3.3' x 12.2"
PTR12108	$ 4,396.20	£ 2,586.00	€ 3.879,00	¥ 724,080	6' x 4.1' x 12.2"
PTR12105	$ 4,603.60	£ 2,708.00	€ 4.062,00	¥ 758,240	8' x 3.3' x 12.2"
PTR12106	$ 5,373.70	£ 3,161.00	€ 4.741,50	¥ 885,080	10' x 3.3' x 12.2"
PTR12107	$ 6,426.00	£ 3,780.00	€ 5.670,00	¥ 1,058,400	12' x 3.3' x 12.2"
PTR12111	$ 7,372.90	£ 4,337.00	€ 6.505,50	¥ 1,214,360	12' x 4.1' x 12.2"
PTR12112	$ 8,282.40	£ 4,872.00	€ 7.308,00	¥ 1,364,160	14' x 4.1' x 12.2"
PTR12116	$ 9,550.60	£ 5,618.00	€ 8.427,00	¥ 1,573,040	14' x 4.9' x 12.2"

SHIPPHi

^fromT*W

.STOCK I

Please contact your local sales office for a quotation including shipping.

THOR ••'•>■*

Sales: 973-579-7227
