Tools of the trade - Vol 18 - 36188 Nd:YAG Mirrors

Optical Systems PPLN Devices

Specifications

â–

Material: Fused Silica

â–

Dia. Tolerance: +0.0/-0.2mm

Spherical Singlets

â–

Front Surface Flatness: λ /10

â–

Thickness: 6.0±0.3mm

â–

Wedge: ≤ 3 arcmin.

Multi-element Lenses

â–

Back Surface: Fine Ground

â–

Surface Quality:

â–

Damage Threshold: See Table

Cylindrical Lenses

10-5 Scratch-Dig

â–

Chamfers: 0.50 x 45°Both sides

â–

Clear Aperture: >80%of Diameter

Aspheric Lenses

λ /10 flatness and surface finishes of 10-5scratch-dig.

Mirrors

These external cavity high energy Nd:YAG lasermirrors have been designed to withstand high CW and peak powers (see the price box below). Each optic is individually tested to ensure better than

Windows & Diffusers

λ = 262–266nm 4th Harmonic

Prisms Gratings Diffractive Optics Polarization Optics

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD

Beamsplitters

NB05-H04$110.00£82.50 115,50¥18,700262-266nm12.7mm0°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse) NB1-H04$170.00£127.50 178,50¥28,900262-266nm25.4mm0°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)NB1-J04$180.00£135.00

Filters & Attenuators

189,00¥30,600262-266nm25.4mm45°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)

Gas Cells

λ = 349–355nm 3rd Harmonic

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD NB1-J08$180.00£135.00 189,00¥30,600349-355nm25.4mm45°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)

λ = 524–532nm 2nd Harmonic

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD NB05-H12$90.00£67.50 94,50¥15,300524-532nm12.7mm0°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse) NB1-H12$150.00£112.50 157,50¥25,500524-532nm25.4mm0°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)NB1-J12$180.00£135.00 189,00¥30,600524-532nm25.4mm45°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)

λ = 1047–1064nm Fundamental

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD NB05-H14$110.00£82.50 115,50¥18,7001047-1064nm12.7mm0°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse) NB1-H14$170.00£127.50 178,50¥28,9001047-1064nm25.4mm0°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)NB1-J14$180.00£135.00 189,00¥30,6001047-1064nm25.4mm45°Ravg>99.7%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)

λ = 532 & 1064nm Dual Wavelength, Fundamental & 2nd Harmonic

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD NB05-H13$140.00£105.00 147,00¥23,800532 & 1064nm12.7mm0°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse) NB1-H13$200.00£150.00 210,00¥34,000532 & 1064nm25.4mm0°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)NB1-J13$180.00£135.00 189,00¥30,600532 & 1064nm25.4mm45°Ravg>99.5%1 MW/cm
2 CW, 5J/cm
2 (10ns Pulse)

Kr-Ion Mirrors

Kr-Ion λ = 520–647nm

λ ANGLE OF ITEM #$£ ¥RANGEDIAMETERINCIDENCE REFLECTIVITY DAMAGE THRESHOLD NB05-H11$120.00£90.00 126,00¥20,400520-647nm12.7mm0°Ravg>99.7%1 kW/cm
2 CW NB1-H11$170.00£127.50 178,50¥28,900520-647nm25.4mm0°Ravg>99.7%1 kW/cm
2 CWNB1-J11$180.00£135.00 189,00¥30,600520-647nm25.4mm45°Ravg>99.7%1 kW/cm
2 CW
