Tools of the trade - Vol 18 - 36188 StableTop™ 450 Series IOptical Tables StableTop™ 450 Series I

BreadboardsBreadboard

The ultimate table for the most demanding research applications, Thorlabs StableTop™ 450 tables employ maximum tuned andbroadband damping, producing an extremely low deflection coefficient.Triple plate double honeycomb StableTop™ technology produces the most rigid composite tables in the industry. The outer skins arethermally matched with the internal plate to minimize bowing due to temperture variations and cycling and to ensure the flatness of thetable is maintained. Mounting holes are sealed making the cleanup of spills easy.

Supports Optical Tables Table Supports Non-Magnetic

PTR11108

Optical TablePTR11108 isshown with self-leveling isolation system PTS503, shown on page 58. For our full line of vibration isolation systems (Active, Passive and Rigid) see pages 56-62.

â–

Flatness: ±0.01mm (±0.004") over any 1m

2 â–

Construction: Triple Plate, Double Honeycomb Core

â–

Damping: Maximum Proprietary Tuned and BroadbandDamping

ULTRA-STABLE GREAT PRICE!

â–

Dynamic Deflection Coefficient: -3 â–

Steel Sealing Cups

US Patent 5,402,734

StableTop 450 Series I – for the most demanding research applications

Optical Tables, 1/4"–20 - Stocked for Immediate DeliveryOptical Tables, 1/4"–20… Call for Lead Time

ITEM#$£ ¥DIMENSIONS (L xW xH) PTR11108$3,886.20£2,286.00 3.429,00 ¥640,0806' x 4.1' x 8.3" PTR11109$4,719.20£2,776.00 4.164,00 ¥777,2808' x 4.1' x 8.3"PTR11110$5,533.50£3,255.00 4.882,50 ¥911,40010' x 4.1' x 8.3" ITEM#$£ ¥DIMENSIONS (L xW xH) PTR11104$3,122.90£1,837.00 2.755,50 ¥514,3606' x 3.3' x 8.3" PTR11105$4,102.10£2,413.00 3.619,50 ¥675,6408' x 3.3' x 8.3" PTR11113$5,623.60£3,308.00 4.962,00 ¥926,2408' x 4.9' x 8.3" PTR11106$4,998.00£2,940.00 4.410,00 ¥823,20010' x 3.3' x 8.3" PTR11114$6,159.10£3,623.00 5.434,50 ¥1,014,44010' x 4.9' x 8.3" PTR11107 $6,159.10£3,623.00 5.434,50 ¥1,014,44012' x 3.3' x 8.3" PTR11111$6,873.10£4,043.00 6.064,50 ¥1,132,04012 x 4.1' x 8.3" PTR11115$7,694.20£4,526.00 6.789,00 ¥1,267,28012' x 4.9' x 8.3" PTR11112 $7,532.70£4,431.00 6.646,50 ¥1,240,68014' x 4.1' x 8.3"PTR11116$8,586.70£5,051.00 7.576,50 ¥1,414,28014' x 4.9' x 8.3"
Please contact your local sales office for a quotation including shipping. Table Supports Sold Separately
