Tables & Breadboards

Sabloi'op™¹ 350 Series II Optical Tables

StableTop™ 350 Series II optical tables feature the same damping, materials and design as the Series I range, but offer increased stiffness when compared to Series I models due to the increased thickness [12.2" (310mm) compared to 8.3" (210mm) thick]. Choose a Series II table if your application would benefit from reduced compliance at a given frequency.

All Thorlabs tabletops offer the highest levels of surface flatness available, high dynamic stiffness and low relative tabletop motion.

Breadboard Supports

Optical Tables

Table Supports

Non-Magnetic

PTQ12113

Table Supports Sold Separately.

Optical Table PTQ12113 is shown with self-leveling isolation system PTS502, shown on page 58. For our full line of vibration isolation systems (Active, Passive and Rigid) see pages 56-62.

US Patent 5402734

StableTop 350

Series II - even more damping, outperforms other manufacturers best tables, but at a competitive price.

Under Table shelves as well as sliding and freestanding shelves for our tables are available, see page 52 for more information.

■ Flatness: ±0.1mm (±0.004") over any 1m²

■ Construction: Triple Plate, Double Honeycomb Core

■ Damping: Proprietary Tuned and Broadband Damping

■ Dynamic Deflection Coefficient: < 0.7 x 10^-3


ITEM#	$	£	€	¥	DIMENSIONS (L x W x H)
PTQ12109	$ 4,632.50	£ 2,725.00	€ 4.087,50	¥ 763,000	8' x 4.1' x 12.2"
PTQ12110	$ 5,659.30	£ 3,329.00	€ 4.993,50	_¥ 932,120	10' x 4.1' x 12.2"
Optical Tables, 1/4"-20... Call for Lead Time
ITEM#	$	£	€	¥	DIMENSIONS (L x W x H)
ITEM#	$	£		¥	DIMENSIONS (L x W x H)
PTQ12104	$ 3,354.10	£ 1,973.00	€ 2.959,50	_¥ 552,440	6' x 3.3' x 12.2"
PTQ12108	$ 3,966.10	£ 2,333.00	€ 3.499,50	¥ 653,240	6' x 4.1' x 12.2"
PTQ12105	$ 4,209.20	£ 2,476.00	€ 3.714,00	¥ 693,280	8' x 3.3' x 12.2"
PTQ12113	$ 5,628.70	£ 3,311.00	€ 4.966,50	_¥ 927,080	8' x 4.9' x 12.2"
PTQ12106	$ 4,902.80	£ 2,884.00	€ 4.326,00	_¥ 807,520	10' x 3.3' x 12.2"
PTQ12114	$ 6,597.70	£ 3,881.00	€ 5.821,50	_¥ 1,086,680	10' x 4.9' x 12.2"
PTQ12107	$ 5,883.70	£ 3,461.00	€ 5.191,50	_¥ 969,080	12' x 3.3' x 12.2"
PTQ12111	$ 6,562.00	£ 3,860.00	€ 5.790,00	_¥ 1,080,800	12' x 4.1' x 12.2"
PTQ12115	$ 7,614.30	£ 4,479.00	€ 6.718,50	_¥ 1,254,120	12' x 4.9' x 12.2"
PTQ12112	$ 7,265.80	£ 4,274.00	€ 6.411,00	_¥ 1,196,720	14' x 4.1' x 12.2"
PTQ12116	$ 8,301.10	£ 4,883.00	€ 7.324,50	¥ 1,367,240	14' x 4.9' x 12.2"

^fromT^W

STOCK li

Please contact your local sales office for a quotation including shipping.

THOR ••'•>■*

Sales: 973-579-7227
