Tools of the trade - Vol 18 - 36188 BK7: Plano-Convex Lenses

PPLN Devices Spherical Singlets

Specifications

â–

Material: BK7

â–

Focal Length Tolerance: ±1%

Multi-element Lenses

â–

Wavelength Range:

â–

Scratch/Dig: 40/20 350nm-2.0µm 633nm (n=1.515082)

â–

Centration: ≤ 3 arcmin.

Cylindrical Lenses

â–

Design Wavelength:

â–

Clear Aperture: >90%

Aspheric Lenses

â–

Dia. Tolerance: +0.00/-0.10mm

Mirrors Windows & Diffusers

RELATED PRODUCTS

Prisms

Ø1” BK7 ESSENTIALSLENS KITS Plano-Convex optics are best used where oneconjugate point (object distance, S, or image distance, S’) is more than five times the other. This lens shape is near best-form for eitherfocusing collimated light or for collimating apoint source.

Gratings

Contains all commonly usedconvex & concave Ø1" lenses.

Diffractive Optics

See page 724

Polarization Optics Beamsplitters

ITEM #$£ ¥

Filters & Attenuators

ESK53-A$1,590.30£1,192.70 1.670,00¥270,351ESK53-B$1,590.30£1,192.70 1.670,00¥270,351 PLANO-CONVEX

Gas Cells

Standard Broadband AR Coatings

COATINGWAVELENGTH$ £ ¥

To order the lens with a standardbroadband AR Coating, add the coatingcode to the Item#, and add the coating cost to the lens price.

-A350-650nm $9.00 £6.75 9,45¥1,530 -B650-1050nm $9.00 £6.75 9,45¥1,530-C 1050-1620nm$12.00 £9.00 12,60¥2,040
Example: LA1116 Coated with 350-650nm Broadband AR Coating is LA1116-Aand the cost would be $18.95 + $9.00 = $27.95.

PLANO-CONVEX LENSES: BK7

DIAfPRICE UNCOATED (For coated lens add suffix)Rtcte
1 fbSUGGESTED ITEM #(mm)(mm)$£ ¥(mm)(mm)(mm)(mm)MOUNT* LA11166.010.0$18.95 £14.21 19,90¥3,2225.22.51.58.4 LA14706.012.0$17.65 £13.24 18,53¥3,001 6.22.31.510.5LMRA6 & LA12226.015.0$17.65 £13.24 18,53¥3,0017.72.11.513.6LMR05 LA17006.030.0$17.35 £13.01 18,22¥2,95015.51.81.528.8 LA15769.012.0$19.65 £14.74 20,63¥3,3416.23.01.59.7LMRA9 & LA14729.020.0$17.65 £13.24 18,53¥3,00110.32.51.518.3 LMR05 LA154012.715.0$19.65 £14.74 20,63¥3,3417.75.11.811.6 LA107412.720.0$19.35£14.51 20,32¥3,29010.34.01.817.4 LA156012.725.0$17.95 £13.46 18,85¥3,05212.93.51.822.7 LA128912.730.0$17.65 £13.24 18,53¥3,00115.53.21.827.9LMR05 LA130412.740.0$17.25 £12.94 18,11¥2,93220.62.81.838.1 LA121312.750.0$17.15 £12.86 18,01¥2,91625.82.61.848.3 LA120712.7100.0$17.15 £12.86 18,01¥2,91651.52.21.898.6 LA185918.020.0$20.65£15.49 21,68¥3,51110.37.11.815.3 LA127018.025.0$19.65 £14.74 20,63¥3,34112.95.51.821.4LH1 LA108518.030.0$19.15 £14.36 20,11¥3,25615.54.71.826.9 LA111918.050.0$19.15 £14.36 20,11¥3,25625.83.41.847.7 LA195125.425.4$22.65 £16.99 23,78¥3,85113.111.71.817.7LMR1LA180525.430.0$22.05 £16.54 23,15¥3,74815.58.62.024.3
1 Edge Thickness given before 0.20mm @ 45°typ. Chamfer.*See next page for details.

564

Sales: 973-579-7227
