Optics

GLASSDESCRIPTIONTRANSMISSION Optical Systems

SF11This glass has a high refractive index420nm to 2.3µmwhich allows for less curvature to create the same amount of refraction. It is useful for constructing optics which would be extremely difficult to make from BK7.GEGermanium plano convex lenses are an 2.0µm to 16µmideal choice for applications from 2.0 µm to 16 µm. Germanium lenses are excellent for long wave infrared imaging, biomedicaland military. ZnSeZinc Selenide plano convex lenses are an 600nm to 16µmideal choice for applications from 600nm to 16 µm. Zinc Selenide lenses are excellent for CO

PPLN Devices Spherical Singlets Multi-element Lenses Cylindrical Lenses Aspheric Lenses Mirrors Windows & Diffusers Prisms Gratings Diffractive Optics Polarization Optics
2

laser applications andinfrared applications for imaging, biomedical and military. The low absorption coefficient of ZnSe makes it ideal for CO

Beamsplitters Filters & Attenuators
2

laser applications.SiSilicon plano convex lenses are an ideal1200nm to 8.0 µmchoice for applications from 1.2 µm to8 µm. Silicon lenses are excellent for infrared applications for imaging, biomedical and military.

Gas Cells

Tools of the trade - Vol 18 - 36188 Spherical Singlet Antireflection Coatings

Normal Incidence Broadband Multilayer Anti-Reflective Coating

â–

Our Most Popular ARCoating

â–

High Performance ARCoating

â–

R â–

Less Angular Sensitivity within Angular Range

â–

Frequently Run Coatings are Listed BelowMost of our standard optics are available withhigh performance multilayer AR coatings toreduce surface reflections to less than 0.5% (per surface) within the specified wavelength ranges. These coatings are designed for angles of incidence between 0°and 30°(0.5 NA). For optics intended to be used at large angles, consider using a custom coatingoptimized at a 45°angle of incidence; these coatings are effective from 25°to 52°. The plot shown below indicates the performance of the standard coatings in thisfamily as a function of wavelength. Broadband coatings have a typical absorptionof 0.25%, not shown in the reflectivity plots.

COATINGWAVELENGTHDESIGN ANGLEUSEFUL ANGLE CODERANGEOF INCIDENCEOF INCIDENCE -UV290-370nm0°0 to 30° -A350-650nm0°0 to 30° -B650-1050nm0°0 to 30°-C1050-1620nm0°0 to 30°

Sales: 973-579-7227

563
