Tables & Breadboards

Tools of the trade - Vol 18 - 36188 Performance™ Series IOptical Tables Performance™ Series I

ScienceDesk™ ScienceDesk™ BreadboardsBreadboard BreadboardsBreadboard

SPECIFICATIONS

â–

Table thickness: 8.3" (210mm)

Supports Supports

â–

Flatness: Flatness: ±0.1mm (0.004") over any 1m

2

Optical Tables Optical Tables

â–

Construction: Double plate, single honeycomb core

â–

Top and Bottom plates:

Table Supports Table Supports

• Matched materials for athermalized design• Magnetic stainless steel, 5mm thick • Top plate is brush finished

Non-Magnetic Non-Magnetic

â–

Core: High-density plated steel honeycomb

â–

Damping: Proprietary broadband damping

â–

Sides: Black laminated-steel sides, slightly inset

â–

Mounting Hole Pattern: • Metric: M6 on 25mm centers• Imperial: 1/4"-20 on 1" centers

Enclosures and accessoriesavailable, see pages 52-53

â–

Edge to first hole center: • Metric Models: 50mm on all sides• Imperial Models 4.1' width: 2.0" on ends & 2.6" on sides • Imperial Models 4.9' width: 2.0" on ends & 2.5" on sides Thorlabs offers a broad range of tables and vi-bration isolation systems that enable the selec-tion of the appropriate components for any ap- plication and environment. The chart on page 35 will assist you in making an appropriate choice. If you should need further assistance,our application engineers are available to helpyou. Call us at 973-579-7227 and just ask for technical support.

â–

Dynamic Deflection Coefficient (max): <1.3 x 10

-3

*

â–

Relative Tabletop Motion (max): <0.27nm (10.5 x 10

-9

in.)*

â–

Deflection Under Load

-5

113kg (250 lb): <1.65µm (6.5 x 10 in.)*

*Measured on a 4 x 8 ft. x 12.2 in. table with isolator transmissibility T<0.01 above 10 Hz, environ-mental vibrations PSD <10
-9 g
2 /Hz.

Performance™ Series

stainless steel top and bottom skin

Cross Section of Tabletop With Double-plate Design Optical Tables, M6 Metric - Stocked for Immediate Delivery

(same material prevents bowing with temperature change)

steel side walls

(provides greater stiffness)

steel honeycomb

(provides a high strength to weight ratio)

hot press bonded

(entire table bonded under high pressure andtemperature providing greater rigidity and stiffness) ITEM#$£ ¥DIMENSIONS (L x W x H) PTM51508 $2,679.20 £1,576.00 2.364,00 ¥441,2802000 x 1250 x 210mm PTM51509$3,542.80 £2,084.00 3.126,00 ¥583,5202500 x 1250 x 210mmPTM51510$4,034.10 £2,373.00 3.559,50 ¥664,4403000 x 1250 x 210mm

Optical Tables, M6 Metric… Call for Lead Time

ITEM#$£ ¥DIMENSIONS (L x W x H) PTM51504$2,278.00 £1340.00 2.010,00 ¥375,2002000 x 1000 x 210mm PTM51505$2,856.00 £1,680.00 2.520,00 ¥470,4002500 x 1000 x 210mm PTM51513$4,063.00 £2,390.00 3.585, 00¥669,2002500 x 1500 x 210mm PTM51506$3,267.40 £1,922.00 2.883,00 ¥538,1603000 x 1000 x 210mm PTM51514$4,343.50 £2,555.00 3.832,50 ¥715,4003000 x 1500 x 210mm PTM51507$3,740.00 £2,200.00 3.300,00 ¥616,0003750 x 1000 x 210mm PTM51511$4,408.10 £2,593.00 3.889,50 ¥726,0403750 x 1250 x 210mm PTM51515$5,550.50 £3,265.00 4.897,50 ¥914,2003750 x 1500 x 210mm PTM51512$5,157.80 £3,034.00 4.551,00 ¥849,5204250 x 1250 x 210mmPTM51516$6,407.30 £3,769.00 5.653,50 ¥1,055,3204250 x 1500 x 210mm
Please contact your local sales office for a quotation including shipping.

Sales: 973-579-7227
