Tools of the trade - Vol 18 - 36188 Performance™ Series IOptical Tables Performance™ Series I

BreadboardsBreadboard

Thorlabs Performance™ optical tables are a cost-effective choicefor general purpose applications. These tables utilize similar con- struction techniques and the same high quality materials as the StableTop™ range. With a single steel core and broadband damp- ing, this series offers enhanced dynamic rigidity and stiffness. The Performance series tabletops are ideally suited for less demand-ing general photonics applications, such as general spectroscopy and multimode fiber optical setups. They are also good for micropositioning and non-interferometric applications.

Supports Optical Tables Table Supports Non-Magnetic

PTM11108

Optical Table PTM11108 isshown with self-leveling iso-lation system PTS503, shownon page58. For our full lineof vibration isolation systems(Active, Passive, and Rigid)see pages 56-62.

US Patent 5402734

Performance Series I– suited for less demanding general photonics applications

The Performance tabletops features:

â–

Flatness: ±0.1mm (±0.004") over any 1m

2 â–

Athermalized Design for Excellent Thermal Stability

â–

Double Plate, Single Honeycomb Core

â–

Minimal Deflection Under Load

â–

Damping: Proprietary Broadband Damping

â–

High Density Honeycomb Core

â–

Excellent Surface Flatness, Achieved by Using a SingleState-Of-The-Art Material and a Thermal Bonding ProcessUnder Pressure Optical Tables, 1/4"–20 - Stocked for Immediate Delivery

ITEM#$£ ¥DIMENSIONS (L X W X H) PTM11108$2,679.20£1,576.00 2.364,00 ¥441,2806' x 4.1' x 8.3" PTM11109$3,542.80 £2,084.00 3.126,00 ¥583,5208' x 4.1' x 8.3" PTM11113$4,063.00 £2,390.00 3.585,00 ¥669,2008' x 4.9' x 8.3" PTM11110$4,034.10 £2,373.00 3.559,50 ¥664,440 10' x 4.1' x 8.3"PTM11111$4,408.10 £2,593.00 3.889,50 ¥726,040 12' x 4.1' x 8.3"

Optical Tables, 1/4"–20… Call for Lead Time

ITEM#$£ ¥DIMENSIONS (L X W X H) PTM11101$2,125.00£1,250.00 1.875,00 ¥350,0006' x 2.5' x 8.3" PTM11104$2,278.00 £1,340.00 2.010,00 ¥375,2006' x 3.3' x 8.3" PTM11105$2,856.00 £1,680.00 2.520,00 ¥470,4008' x 3.3' x 8.3" PTM11106$3,267.40£1,922.00 2.883,00 ¥538,160 10' x 3.3' x 8.3" PTM11114$4,343.50 £2,555.00 3.832,50 ¥715,40010' x 4.9' x 8.3" PTM11107$3,740.00£2,200.00 3.300,00 ¥616,000 12' x 3.3' x 8.3" PTM11115$5,550.50 £3,265.00 4.897,50 ¥914,200 12' x 4.9' x 8.3" PTM11112$5,157.80 £3,034.00 4.551,00 ¥849,520 14' x 4.1' x 8.3"PTM11116$6,407.30 £3,769.00 5.653,50 ¥1,055,320 14' x 4.9' x 8.3"
Please contact your local sales office for a quotation including shipping. Table Supportssold separately

40

Sales: 973-579-7227
