Tools of the trade - Vol 18 - 36188 Breadboard Support Frames - Rigid

Breadboards

Metric & Imperial Compatible

BreadboardSupports

Rigid Support Frame

Optical Tables Table Supports Non-Magnetic

800mm (32") Height Standard – 700mm (28") Height Available Upon Request

Specifications

Load Capacity: 700 kg (1545 lbs.) Height Adjustment Range:• Leveling pads: ±0.375" (±9.5mm) • Leveling feet: ±0.2" (±5mm) Finish: Black Paint This series of rigid frames is designedto provide a low cost solution for supporting optical breadboards in a laboratory or production environment and is ideal for applications where vibrationisolation is not a critical factor. Casters are also available, see price box below (Part number PWA061). Support Frames Accommodate Breadboard Sizes as Large as1.25m x 2.5m (4' x 8') Solid, All Steel Construction Manually Leveling Pads to Compensate for Uneven Floors Set of Casters Available(Part number PWA061) Rigid Support Frames, 800mm Height

ITEM$£ ¥DESCRIPTION PFL52501$1,094.80 £644.00 966,00 ¥180,320750 x 750mm, (2.5' x 2.5') PFL52502$1,101.60 £648.00 972,00 ¥181,440900 x 750mm, (3' x 2.5') PFL52505$1,108.40 £652.00 978,00 ¥182,560900 x 900mm, (3' x 3') PFL52503$1,113.50 £655.00 982,50 ¥183,4001200 x 750mm, (4' x 2.5') PFL52506$1,123.70 £661.00 991,50 ¥185,0801200 x 900mm, (4' x 3') PFL52508$1,150.90 £677.00 1.015,50 ¥189,5601200 x 1200mm, (4' x 4') PFL52504$1,122.00 £660.00 990,00 ¥184,8001500 x 750mm, (5' x 2.5') PFL52507$1,132.20 £666.00 999,00 ¥186,4801500 x 900mm, (5' x 3') PFL52509$1,159.40 £682.00 1.023,00 ¥190,9601500 x 1200mm, (5' x 4')PWA061$112.20£66.00 99.00¥18,480Set of Casters
*Please contact your local sales office for a quotation including shipping.

Performance™ &PerformancePlus™ Series Optical Breadboards

Thorlabs has a selection of breadboards that are intended tofit our SuperDamp™, Pump&Go™ and Rigid workstations. Our breadboards feature: Plated steel honeycomb core & internal damping provideboth static and dynamic rigidity Magnetic stainless steel top and bottom plate See Our Full Selection of OpticalBreadboards on Pages 15–27. Excellent surface flatness, achieved by using a single state-of-the-art material and a thermal bonding process

34

Sales: 973-579-7227
