Laser Diode Technologies

T03 Collimation Package

Laser/ TEC Drivers BenchtopLaser/TEC Drivers

The LDH3 T0-3 Laser Diode Kit can be used oneof two ways: If the laser output power is low and no heat sinking is required, the laser can be mounted directly to the LDH3 (as shown in the photograph). For higher power lasers or where better temperature regulation is required, the LDH3 can be mounted directly onto any heat sink that is designed to accept T03 laser packages.

â–

Ideal forCollimatingHigh Power Laser Diodes

PlatformsLaser/TEC OEM Drivers

â–

CompletePackageas shown in the photograph, each unit is shipped assembled less the laser and the aspheric lens.

Laser Mounts

LASER NOT INCLUDED

Laser Diodes Pigtailed Lasers

â–

Compatible with our extensive line of Ø1" Lens Tubes (See pages 189 through 202)

â–

Broad selection of Collimation Optics (Sold separately, see page 599).

Laser Modules Accessories

ITEM#METRIC ITEM#$£ ¥USED WITH LDH3-P1LDH3-P1/M$113.00£84.75 118,65¥19,210C110TM, C220TM &C230TM*
*See page 532 for optics.

Tools of the trade - Vol 18 - 36188 ø

9mm &

ø

5.6mm Collimation Packages

â–

Ideal for Collimating High PowerLaser Diodes

â–

Complete Package as shownin the photograph, each unit is shippedassembled less the laser and the aspheric lens.

â–

Compatible with our extensive line of Ø1" Lens Tubes(See pages 189 through 202)

SOLD SEPARATELY â–

Broad selection of Collimation Optics (Sold separately, see page 599).

ITEM#METRIC ITEM#$£ ¥DESCRIPTIONUSED WITH LDH9-P1LDH9-P1/M$91.00£68.25 95,55¥15,470Ø5.6mm & Ø9mm Laser Collimation KitC110TM, C220TM &C230TM
*Optics sold separately

T03 Laser Mount Universal Laser Mount:5.6mm & 9mm

This laser mount is designed to accept standard T03 laser packages. The recessed pocket in which the T03 laser fits is machined oversizedto allow coarse alignment of the laser packagewithin the cage assembly (See pages 194-212).

LM9F Adapter for 5.6mm laser diodes included SAMPLE LASER (Not Included) ITEM #$£ ¥DESCRIPTION ITEM #$£ ¥DESCRIPTION CP04$64.00£48.00 67,20¥10,880Cage Mount for T03 Lasers LM9F$24.00£18.00 25,20¥4,0805.6mm & 9mm Laser Mount
*Universal Design; Imperial &Metric. Compatible with 5.6mm & 9.0mm Lasers.

ø

9mm &

ø

5.6mm Laser Mount

S1LM9

The S1LM9 laser diode mount is designed to allow Ø5.6mm and Ø9mm laserpackages to be utilized within our SM1-Series lens tubes. The slip plate translator (See page 204) is an ideal accessory for incorporating this adapter into our cageassemblies; the coarse X-Y movement provides an easy method for compensatingfor tolerance errors within the laser package.

SM1 THREADS
Sample Laser(Not Included see pages436 &437 for acomplete listing.) ITEM #$£ ¥DESCRIPTION S1LM9$26.00£19.50 27,30¥4,420SM1 Series Mountfor 5.6mm & 9mm Lasers RETAINING RING

Sales: 973-579-7227

435
