Tools of the trade - Vol 18 - 36188 14" x 18" Instrumentation Shelf Kinematic Breadboard Seats

ScienceDesk™

The S1418 instrumentation shelf attaches directly to a P-Series post (sold separately on page 28).The plate can be rotated via an access hole in the top surface after it has been assembled. For largeuneven loads, four corner mounting holes areprovided. These holes can be used with our Ø 1/2" posts and postholders (See page 70).

DESIGN ALLOWS EASY ROTATIONAFTER ASSEMBLY

Breadboards Breadboard Supports Optical Tables Table Supports

â–

Large 14" x 18" x 1/4" Heavy Duty Platform

Non-Magnetic

â–

Design Allows Easy Rotation After Assembly

Post sold separately BOTTOMVIEW ITEM#METRIC ITEM#$£ ¥DESCRIPTION S1418S1418/M$78.00£58.50 81,90¥13,26014" x 18" Instrumentation Shelf

Rubber Dampening Feet

â–  RDF1

Accepts M6 or 1/4-20 Socket Head Cap Screws (Not Included)

â–

Helps Reduce Shock and Vibration

â–

Useful for Uneven Surfaces

â–

1.0" Diameter Helps Displace Heavy Loads These Rubber Damping Feet are useful to help stabilize your AluminumBreadboards. Mount one under each corner to help reduce vibrations and to compensate for uneven work table surfaces. They accept either metric or imperial socket head cap screws found in HW-KIT2 and HW-KIT2/M hardware kits (Seepage 99. Rubber Damping Feet 14" x 18" Instrumentation Shelf

ITEM$£ ¥DESCRIPTION RDF1$5.00£ 3.75 5,25¥,850Rubber Dampening Feet, set of 4 â–

3 Radial V-groove Kinematic Design

â–

Build Your Own Kinematic Base SystemFrom Our Breadboards

â–

Magnetically Coupled With High Strength Rare-earth Magnets

Breadboards Soldon Pages 15-27

â–

1/4"-20 (M6) on 1" (25mm) Centers TurnsAny Breadboard Into a Kinematic Base

â–

Slotted Design Allows the 3 V-groovesto be Aligned to a Common Center forGreatest Stability

â–

Universal DesignMetric andImperial Compatibility The KBS98 kinematic seats can be used to convert any breadboard into a kinematicplatform that can be removed and replaced with a high degree of accuracy. Two ofthe three seats of each set (top & bottom) haveelongated slots to allow the seats to all point to a common center in the middle of the breadboard.

ITEM$£ ¥DESCRIPTION KBS98$128.00 £ 96.00 134.40¥ 21,760Set of Kinematic Breadboard Seats

Sales: 973-579-7227
