Tools of the trade - Vol 18 - 36188 Breadboard Accessories – Variable Height Posts

Breadboards Breadboard Supports

PF175 sold separately see page 28

Optical Tables Table Supports

BLP01 Supplied Individually Breadboard Sold separately

Non-Magnetic

Breadboards sold separatelyon pages 15-27

MAXIMUM LOAD PER POST: 500LBS.

Leveling Posts The height of an optical breadboard can be adjusted simply by turning an adjustment ring on each leveling post.

â–

A Locking Ring is Provided to Lock the Device Into Position

â–

Leveling Posts are Made From Stainless Steel and are Supplied Individually. Leveling Posts

ITEM$£ ¥DESCRIPTION BLP01$88.00 £66.00 92,40 ¥14,9601/4"-20 Leveling Post BLP01/M$88.00 £66.00 92,40 ¥14,960M6 Metric Leveling PostPF175$16.00£12.00 16,80¥2,720P-Series Clamping Fork

Fixed Standoff Posts

Standoff posts provide a simple way to mount a Thorlabsbreadboard above an optical table.

(Adds 0.24"to the height) â–

Standoff Posts are Made from Stainless Steel

PF175P1.5PB4 â–

PB4 Pedestal Base Adds 0.24" to the Overall Height of the Post

â–

Ø1.5" (38mm)

PB4 â–

1/4"-20 (M6) Tap Both Ends Standoff Posts

ITEM#METRIC ITEM#$£ ¥DESCRIPTION P1.5P30/M$21.00£15.75 22,05¥3,5701.5" (30mm) Fixed Standoff Post P2P50/M$25.00£18.75 26,25¥4,2502" (50mm) Fixed Standoff Post P3P75/M$31.00£23.25 32,55¥5,2703" (75mm) Fixed Standoff Post P4P100/M$36.00£27.00 37,80¥6,1204" (100mm) Fixed Standoff Post P5P125/M$42.00£31.50 44,10¥7,1405" (125mm) Fixed Standoff Post P6P150/M$46.00£34.50 48,30¥7,8206" (150mm)Fixed Standoff Post P8P200/M$52.00£39.00 54,60¥8,8408" (200mm) Fixed Standoff Post P10P250/M$58.00£43.50 60,90¥9,86010" (250mm) Fixed Standoff Post P14P350/M$74.00£55.50 77,70¥12,58014" (350mm) Fixed Standoff Post PB4PB4/M$12.00£9.00 12,60¥2,040P-Series Pedestal BasePF175PF175$16.00£12.00 16,80¥2,720P-Series Clamping Fork

28
