Laser Diode Technologies

Tools of the trade - Vol 18 - 36188 PRO8000 Modular Controller Systems

Laser/TEC Drivers Benchtop All PRO8000 series controllers are equipped with IEEE 488.2 and RS-232C interfaces as standard features. Each system is delivered withLabVIEW™ and LabWindows™/CVI driversto support the individual modules, as well as their integration into a comprehensive test and measurement system. Easy Operation
Laser/TEC DriversPlatforms All modules are self- identifying and are operated via menu- driven softkeys, the analog values are set with a rotary knob on the front panel. All values are shown on a 4 x 20 character alphanumeric vacuum fluorescence display. The functions of the softkeys change in accordance with the activated module. A key-operated power switch protects the PRO8000 series against unauthorized use.
Laser/TEC OEM Drivers Laser Mounts Laser Diodes Pigtailed Lasers

PRO800 Bench Top Chassis

Laser Modules The smaller PRO800 chassis offers a menu driven, flexible platform that supports a multitude of electrical and optical modules to address a wide variety of applications. This chassis is a bench top system that supports two modules. It is ideal for the lab environment or as a benchtop system in crowded manufacturing environments.
Accessories This benchtop chassis has all the samefeatures as the larger eight slot chassis.
PRO800 ChassisModules Sold Separately Additional Light Source Modules for the PRO8000 series:
â–  DFB laser sources, pages 494-503.
â–  DWDM laser sources in the S, C & L-band, pages 500-501.
â–  Optical switch modules, pages 842-845.

PRO8000 Series Specifications PRO800PRO8000PRO8000-4

Slots288 Maximum Output Current for all modules8A16A32A Maximum Power Consumption230VA480VA820VA DisplayAlphanumeric Display with 4 x 20 Characters Operation Menu-Driven Setting Function Keys and Rotary Knob Protection featuresKey-Operated Power Switch TTL Modulation Frequency range
1 DC to 10kHz TTL Duty cycle
1 Selectable TTL Modulation InputBNC TTL Trigger Output BNC IEEE 488.2 Interface 24-pin IEEE Jack (Rear Panel) RS-232C Interface9-pin D-sub Plug (Rear Panel) Chassis Ground4mm Banana (Rear Panel) Line Voltage100V, 115V and 230V AC ±10% Line frequency50 to 60Hz Operating temperature0 to + 40°C Storage temperature– 40°C to + 70°C Relative Humidity
1 external synchronous current modulation for all cards in the chassis ITEM$£ ¥DESCRIPTION PRO800$1,798.80£999.33 1.499,00¥239,8402 Slot Modular Benchtop Chassis PRO8000$2,398.80£1,332.67 1.999,00¥319,8408 Slot Modular Rack Chassis PRO8000-4$3,238.80£1,799.33 2.699,00¥431,8408 Slot High Power Modular Rack Chassis PRO8000-R32$62.40£34.67 52,00¥8,32019" Mounting Kit for PRO8000 PRO8000-R42$86.40£48.00 72,00¥11,52019" Mounting Kit for PRO8000-4PRO8000-C$24.00£13.33 20,00¥3,200PRO8000 Front Cover Plate Sales: 973-579-7227
405
