PerformancePlus™ Series Optical Breadboards–(110mm)4.3"Thick

Breadboards PerformancePlus™ Optical Breadboards are designed specificallyfor demanding R&D applications. They combine all the features of the Performance™ breadboards but with enhanced damping, increased rigidity and sealed mounting holes.
â–  Enhanced Damping Improves Dynamic Performance for the Most Critical Laboratory Applications
Breadboard Supports â–  Sealed Mounting Holes Make it Simple to Contain and Clean Up Spills or Retrieve Small Objects
Optical Tables â–  â–  Plated Steel Sealing Cups Honeycomb Structure Triple plate StableTop™ Construction Significantly Increases Rigidity
Table Supports Non-Magnetic

Tools of the trade - Vol 18 - 36188 BEST

FORDEMANDING R&DAPPLICATIONS!

PerformancePlus™ with enhanced damping and increased rigidity along with sealing cups.

Specifications

â–  Bottom Plate: Magnetic Stainless Steel, 5mm (3/16") Thick
â–  Flatness: ±0.10mm (0.004") over any 0.3m
2 area
â–  Sides: Black Laminated Steel
â–  Thickness: 4.3" (110mm)
â–  Damping: Enhanced
â–  Construction: Athermalized Design with Matching Plate Materials for Maximum Thermal Stability
â–  Mounting Hole: • Imperial: 1/4"-20 on 1" Centers • Metric: M6 on 25mm Centers
â–  Main Core: High Density Plated Steel Honeycomb
â–  Intermediate Core: Plated Steel Sealing Cup HoneycombStructure, 13mm (0.15") Thick; Cell Size Approximately1.6cm
â–  Edge of Top Plate to First Hole:
2 (0.25in.
2 ) • Imperial: 2" • Metric: 50mm
â–  Top plate: Magnetic Stainless Steel, 5mm (3/16") Thick,Brush Finished
â–  Maximum Screw Depth: 16mm (5/8") From Breadboard Surface

Expanding The Line

Our ScienceDesk™ frames are designed to accept from threeof our breadboard lines - the Ultralight™, Performance™ and PerformancePlus™ – allowing flexibility in creating a workstationwith an array of vibration isolation possibilities. Features include:
â–  Flexible Workstation System With a Wide Range of Accessories
â–  Six Standard Size Frames With 765mm (30.6") Height:• 600 x 900mm• 750 x 750mm • 750 x 900mm • 750 x 1200mm • 900 x 900mm • 900 x 1200mm
â–  Active, Passive and Rigid Isolation Systems
PSH501 â–  ESD Compliant Shelving and Accessories
â–  Ergonomic Design
â–  Heavy Duty Casters
