Tools of the trade - Vol 18 - 36188 PerformancePlus™ Series Optical Breadboards 60mm Thick

ScienceDesk™

Metric PerformancePlus™Optical Breadboards, 60mm Thick - Stocked for Immediate Shipment

Breadboards

ITEM#$£ ¥DIMENSIONS

Breadboard

PBI51505$792.20 £466.00 699,00 ¥130,480600 x 600 x 60mm

Supports

PBI51510*$986.00 £580.00 870,00 ¥162,400 750 x 750 x 60mm PBI51506*$1,011.50 £595.00 892,50 ¥166,600 900 x 600 x 60mm

Optical Tables

PBI51511*$1,300.50 £765.00 1.147,50 ¥214,200 900 x 750 x 60mm PBI51514*$1,343.00 £790.00 1.185,00 ¥221,200900 x 900 x 60mm

Table Supports

PBI51512*$1,480.70 £871.00 1.306,50 ¥243,880 1200 x 750 x 60mm PBI51515*$1,565.70 £921.00 1.381,50 ¥257,880 1200 x 900 x 60mm

Non-Magnetic

PBI51508$1,341.30 £789.00 1.183,50 ¥220,9201500 x 600 x 60mm PBI51513$1,649.00 £970.00 1.455,00 ¥271,600 1500 x 750 x 60mm PBI51516$1,790.10 £1,053.00 1.579,50 ¥294,840 1500 x 900 x 60mmPBI51517$2,065.50 £1,215.00 1.822,50 ¥340,200 1800 x 900 x 60mm

Metric PerformancePlus™Optical Breadboards, 60mm Thick… Call for Lead Time

ITEM#$£ ¥DIMENSIONS PBI51501$571.20 £336.00 504,00 ¥94,080 300 x 300 x 60mm PBI51502$646.00 £380.00 570,00 ¥106,400600 x 300 x 60mm

For more information,contact a sales representative at any location listed on theback cover of the catalog.

PBI51528$714.00£420.00 630,00¥117,600600 x 450 x 60mm PBI51503$765.00 £450.00 675,00 ¥126,000900 x 300 x 60mm PBI51504$848.30 £499.00 748,50 ¥139,7201200 x 300 x 60mm PBI51507$1,157.70 £681.00 1.021,50 ¥190,6801200 x 600 x 60mm PBI51523$2,000.90 £1,177.00 1.765,50 ¥329,5601250 x 1250 x 60mm PBI51524$2,249.10 £1,323.00 1.984,50 ¥370,4401500 x 1250 x 60mm PBI51509$1,645.60 £968.00 1.452,00 ¥271,0401800 x 600 x 60mm PBI51525$2,621.40 £1,542.00 2.313,00 ¥431,7601800 x 1250 x 60mmPBI51527$3,281.00 £1,930.00 2.895,00 ¥540,4002500 x 1250 x 60mm
*These breadboards can be used with our ScienceDesk™ workstations. See pages 2-14 to learn more.Please contact your local sales office for a quotation including shipping.

Workframes See Page 31

Thorlabs workstations are available with a choice of active, passive or rigid isolation supports to meet specific needs and budgetrequirements. The basic workstationconfiguration includes a breadboard working surface and a support system. The working height is nominally 790mm (31") for 60mm (2.4") thick breadboards, and840mm (33") for 110mm (4.3") thickbreadboards. The workstation utilizes a welded frame that is shipped fully assembled. It is rigidly designed and provides a firm, stable work surface. The frame is finished with a high-durability, matte black polyurethane paint. All workstations are provided with a set of four leveling feet. Each leveling foot isthreaded to enable fine height adjustmentand accurate alignment. This eliminates the possibility of impaired isolation performance due to non-level floors. The leveling feet incorporate a lock nut toensure the adjustment is fixed. Casters(optional) are located beneath tie bar to allow for easy movement of the workstation.

NanoMax™ Nanopositioning Stages

We have expanded our selection of single, dual andthree axis stages. Complete systems and kits are available. NanoMax &Stepper MotorCustomer ConfiguredNanoMax StagesNanoMax & StepperMotor with PiezoNanoMax 3 Axis Stage

See Page 274 for More Information Sales: 973-579-7227
