Tools of the trade - Vol 18 - 36188 PerformancePlus™ Series Optical Breadboards–2.4" Thick

Breadboards

PerformancePlus™ Optical Breadboards are designed specifically for demanding R&D applications. They combine all the featuresof the Performance™ breadboards but with enhanced damping, increased rigidity and sealing cups.

Breadboard Supports

â–

Triple-plate Double Core StableTop™ ConstructionSignificantly Increases Rigidity

Optical Tables

â–

Enhanced Damping Improves Dynamic Performance for the Most Critical Laboratory Applications

Specifications

Table Supports

â–

Flatness: ±0.10mm (0.004") Over Any 0.3m

2

Area

â–

Sealed Mounting Holes Make it Simple to Contain and Clean Up Spills or Retrieve Small Objects

â–

Thickness: 2.4" (60mm)

Non-Magnetic

â–  â–

Plated Steel Sealing Cup Honeycomb Structure Construction: Triple-plate, Double Honeycomb-core,Athermalized Design With Matching Plate Materials forMaximum Thermal Stability

â–

Damping: Enhanced

â–

Main Core: High Density Plated Steel Honeycomb

â–

Intermediate Core: Plated Steel Sealing Cup HoneycombStructure, 13 mm (0.15") Thick. Cell Size Approximately1.6cm

2

(0.25in.

2

)

â–

Top plate: Magnetic Stainless Steel, 5mm (3/16") Thick,Brush Finished

â–

Bottom Plate: Magnetic Stainless Steel, 5mm (3/16") Thick

â–

Sides: Black Laminated Steel

â–

Hole Spacing: • Imperial: 1/4"-20 on 1" Centers • Metric: M6 on 25mm Centers

â–

Edge of Top Plate to First Hole: • Imperial: 2" • Metric: 50mm

USED FOR

â–

Maximum Screw Depth: 16 mm (5/8") From Breadboard Surface

DEMANDING

APPLICATIONS!

PerformancePlus™ with enhanced damping and increased rigidity along with sealing cups.

PerformancePlus™Optical Breadboards, 2.4" Thick - Stocked for Immediate Shipment

ITEM#$£ ¥DIMENSIONS PBI11105$795.60 £468.00 702,00 ¥131,040 2' x 2' x 2.4" PBI11110*$986.00 £580.00 870,00 ¥162,400 2.5' x 2.5' x 2.4" PBI11106*$1,014.90 £597.00 895,50 ¥167,160 3' x 2' x 2.4" PBI11111*$1,307.30 £769.00 1.153,50 ¥215,320 3' x 2.5' x 2.4" PBI11114*$1,349.80 £794.00 1.191,00 ¥222,320 3' x 3' x 2.4" PBI11107$1,164.50 £685.00 1.027,50 ¥191,8004' x 2' x 2.4" PBI11112*$1,485.80 £874.00 1.311,00 ¥244,720 4' x 2.5' x 2.4" PBI11115*$1,574.20 £926.00 1.389,00 ¥259,280 4' x 3' x 2.4" PBI11116$1,800.30 £1,059.00 1.588,50 ¥296,520 5' x 3' x 2.4"PBI11117$2,077.40 £1,222.00 1.833,00 ¥342,160 6' x 3' x 2.4"

PerformancePlus™Optical Breadboards, 2.4" Thick… Call for Lead Time

ITEM#$£ ¥DIMENSIONS PBI11101$571.20 £336.00 504,00 ¥94,080 1' x 1' x 2.4" PBI11102$647.70 £381.00 571,50 ¥106,6802' x 1' x 2.4" PBI11122$714.00£420.00 630,00¥117,6002' x 1.5' x 2.4" PBI11103$766.70 £451.00 676,50 ¥126,280 3' x 1' x 2.4" PBI11104$850.00 £500.00 750,00 ¥140,000 4' x 1' x 2.4" PBI11118$2,006.00£1,180.00 1.770,00¥330,4004' x 4' x 2.4" PBI11108$1,348.10 £793.00 1.189,50 ¥222,040 5' x 2' x 2.4" PBI11113$1,655.80 £974.00 1.461,00 ¥272,7205' x 2.5' x 2.4" PBI11119$2,329.00 £1,370.00 2.055,00 ¥383,6005' x 4' x 2.4" PBI11109$1,654.10 £973.00 1.459,50 ¥272,4406' x 2' x 2.4" PBI11120$2,558.50 £1,505.00 2.257,50 ¥421,4006' x 4' x 2.4"PBI11121$3,243.60 £1,908.00 2.862,00¥534,2408' x 4' x 2.4"
*These breadboards can be used with our ScienceDesk™ workstations. See pages 2-14 to learn more.Please contact your local sales office for a quotation including shipping.

24

Sales: 973-579-7227
