	ScienceDesk™
		Breadboards
		Optical Tables

Tables & Breadboards

Performance™ Series Optical Breadboards - 110mm Thick

Metric Performance™ Breadboards, 110mm Thick - Stocked for Immediate Shipment


ITEM#	$		£		€				DIMENSIONS
PBH52510*	$	839.80	£	494.00	€	741,00	¥	138,320	750 x 750 x 110mm
PBH52511*	$	1,076.10	£	633.00	€	949,50	¥	177,240	900 x 750 x 110mm
PBH52514*	$	1,094.80	£	644.00	€	966,00	¥	180,320	900 x 900 x 110mm
PBH52507	$	989.40	£	582.00	€	873,00	¥	162,960	1200 x 600 x 110mm
PBH52512*	$	1,247.80	£	734.00	€	1.101,00	¥	205,520	1200 x 750 x 110mm
PBH52515*	$	1,295.40	£	762.00	€	1.143,00	¥	213,360	1200 x 900 x 110mm
PBH52513	$	1,405.90	£	827.00	€	1.240,50	¥	231,560	1500 x 750 x 110mm
PBH52516	$	1,507.90	£	887.00	€	1.330,50	¥	248,360	1500 x 900 x 110mm
PBH52517	$	1,759.50	£	1,035.00	€	1.552,50	¥	289,800	1800 x 900 x 110mm

Non-Magnetic

Metric Performance™ Breadboards, 110mm Thick... Call for Lead Time


ITEM#		$		£		€		¥	DIMENSIONS
ITEM#		$		£		€		¥	DIMENSIONS
PBH52506*	$	839.80	£	494.00	€	741,00	¥	138,320	900 x 600 x 110mm
PBH52518	$	1,122.00	£	660.00	€	990,00	¥	184,800	1000 x 750 x 110mm
PBH52519	$	1,319.20	£	776.00	€	1.164,00	¥	217,280	1000 x 1000 x 110mm
PBH52523	$	1,592.90	£	937.00	€	1.405,50	¥	262,360	1250 x 1250 x 110mm
PBH52508	$	1,122.00	£	660.00	€	990,00	¥	184,800	1500 x 600 x 110mm
PBH52521	$	1,684.70	£	991.00	€	1.486,50	¥	277,480	1500 x 1000 x 110mm
PBH52524	$	1,951.60	£	1,148.00	€	1.722,00	¥	321,440	1500 x 1250 x 110mm
PBH52509	$	1,256.30	£	739.00	€	1.108,50	¥	206,920	1800 x 600 x 110mm
PBH52525	$	2,210.00	£	1,300.00	€	1.950,00	¥	364,000	1800 x 1250 x 110mm
PBH52522	$	2,023.00	£	1,190.00	€	1.785,00	¥	333,200	2000 x 1000 x 110mm
PBH52526	$	2,510.90	£	1,477.00	€	2.215,50	¥	413,560	2000 x 1250 x 110mm
PBH52527	$	2,866.20	£	1,686.00	€	2.529,00	¥	472,080	2500 x 1250 x 110mm

*These breadboards can be used with our ScienceDesk™ workstations. See pages 2-14 to learn more. Please contact your local sales office for a quotation including shipping.

Rigid Support Frames

Breadboard Accessories

See Page 28

►1

Rigid (Non-Isolating) Support Frames

These inexpensive frames are ideal for I applications in which vibration isolation is not a critical factor.

■ Load Capacity: 700kg (1545 lbs)

■ Height Adjustment Range: • Leveling Pads:

+ 19mm/-0mm (to 0.757-0") •Leveling Feet: ±10 mm (± 0.4")

■ Finish: Black Paint

Kinematic Breadboard Seats

See Page 34 for More Information

THOR ^

Sales: 973-579-7227
