Performance™ Series Optical Breadboards – 4.3" Thick

Breadboards

Thorlabs Performance™ optical breadboards provide high performance at an economical price. A favorite of OEMs, these all steelbreadboards are also an ideal laboratory platform for optical and laser experiments.The Performance breadboards feature:

Breadboard Supports

â–

Athermalized Design for Excellent Thermal Stability

Optical Tables

â–

Minimal Deflection Under Load

â–

Plated Steel Honeycomb Core & Internal Damping provide both Static and Dynamic Rigidity

Table Supports

â–

Magnetic Stainless Steel Top and Bottom Plate

â–

Excellent Surface Flatness, Achieved by Using a Single State of the Art Material and a Thermal Bonding Process

Non-Magnetic

Tools of the trade - Vol 18 - 36188 A FAVORITE OF OEM’S!

Specifications

â–

Flatness: (0.13mm) ±0.005" Over any 0.3m

2

Area

â–

Thickness: (110mm)4.3"

â–

Construction: Double-plate, Single Honeycomb-Core, Athermalized Design

â–

Damping: Nominal

â–

Core: High Density Plated Steel Honeycomb

â–

Top plate: Magnetic Stainless Steel, 5mm(3/16") Thick, Brush Finished

â–

Bottom Plate: Magnetic Stainless Steel, 5mm(3/16") Thick

â–

Sides: Black Laminated Steel

â–

Mounting Holes: Not Sealed

â–

Hole Spacing: • Imperial: 1/4"-20 on 1" Centers• Metric: M6 on 25mm Centers

â–

Edge of Top Plate to First Hole: • Imperial: 2"• Metric: 50mm Performance™Breadboards, 4.3" Thick - Stocked for Immediate Shipment

ITEM#$£ ¥DIMENSIONS PBH12110*$839.80£494.00 741,00¥138,320 2.5' x 2.5' x 4.3" PBH12111*$1,081.20£636.00 954,00¥178,0803' x 2.5' x 4.3" PBH12114*$1,098.20£646.00 969,00¥180,8803' x 3' x 4.3" PBH12107$991.10£583.00 874,50¥163,2404' x 2' x 4.3" PBH12112*$1,264.80£744.00 1.116,00¥208,3204' x 2.5' x 4.3" PBH12115*$1,298.80£764.00 1.146,00¥213,9204' x 3' x 4.3" PBH12113$1,412.70£831.00 1.246,50¥232,6805' x 2.5' x 4.3" PBH12116$1,511.30£889.00 1.333,50¥248,9205' x 3' x 4.3"PBH12117$1,764.60£1,038.00 1.557,00¥290,6406' x 3' x 4.3"

Performance™Breadboards, 4.3" Thick… Call for Lead Time

ITEM#$£ ¥DIMENSIONS PBH12106*$821.10£483.00 724,50¥135,2403' x 2' x 4.3" PBH12118$1,586.10£933.00 1.399,50¥261,2404' x 4' x 4.3" PBH12108$1,152.60£678.00 1.017,00¥189,8405' x 2' x 4.3" PBH12119$1,941.40£1,142.00 1.713,00¥319,7605' x 4' x 4.3" PBH12109$1,259.70£741.00 1.111,50¥207,4806' x 2' x 4.3" PBH12120$2,247.40£1,322.00 1.983,00¥370,1606' x 4' x 4.3"PBH12121$2,748.90£1,617.00 2.425,50¥452,7608' x 4' x 4.3"
*These breadboards can be used with our ScienceDesk™ workstations. See pages 2-14 to learn more.Please contact your local sales office for a quotation including shipping.
