Motion Control

Tools of the trade - Vol 18 - 36188 Single Channel apt™ Stepper Motor Controller… Page 2 of 2

Translation StagesMotorized Mirror Mounts

Specifications

â–  Compatible Motors
â–  Motor speeds: Up to 600 RPM(for 200 full step motor)
â–  Input/Output: • Peak Powers: 5 to 50W• 500,000 counts/sec
Rotation Stages3 Axis Flexure Stages • Motor Drive Channel(15-Pin D-type Female) Average Power: 25 W Maximum•
â–  Encoder feedback bandwidth: Step Angle Range: 20°to 1.8°•
& Accessories –2-Phase Bipolar MotorDrive Output–Differential QuadratureEncoder Interface–Forward, ReverseLimit Switch Inputs• Coil Resistance (nominal):
â–  General 4 to 15 Ω • Housing Dimensions(W x D x H): 152 x 244 x 104mm (6 x 9.6 x 4.1 in.)• Instrument Weight: 3.18kg (7 lbs)
4, 5 & 6-Axis Stages • Coil Inductance (nominal):
Drive Electronics& Auto-Alignment 4 to 15mH• Rated Phase Currents (nominal):
Actuators & 100mA to 1A
Adjusters Motor Control(15-Pin D-type Female)
â–  Resolution •128 Microsteps per Full Step•200 Step Motor - 25,600Microsteps per Revolution•24 Step Motor - 3072per Revolution –Jog Forward –Jog Back –Enable/Disable Interlock –RS 232Communications Channels–User Outputs/Inputs –Single - ended analog input(0-10 Volt)–Trigger In/Out
â–  Motor Power: Up to 48V/50W(peak)
â–  Input Power Requirements • Voltage: 85-264 VAC• Power: 200W• Fuse: 2A
apt™ Stepper Motor Controller Backview MOTOR DRIVE
123456789101112131415

Features

â–  Full Software GUI Control Suite
â–  Supports 2 Phase Bipolar Steppers up to 50W
â–  High Resolution Micro-stepping Control (for very fine positioning apps)
â–  Differential Encoder Feedback (QEP Inputs)for Closed Loop Positioning
Pin Description Pin Description â–  Stable and Predictable Low Speed Operation (for velocity sensitive apps)
1 Encoder A +ve 9 CW Limit Stwitch 2 Encoder A -ve 10 CCW Limit Switch 3 Encoder B +ve 11 0V User 4 Encoder B -ve 12 Not Used 5 5V User 13 Not Used 6 Not Used 14 Phase B + 7 Phase B - 15 Phase A + 8 Phase A - â–  Auto-Configure Function for all Thorlabs Stages
â–  ActiveX
® software graphical panels
â–  USB Plug-and-Play Plus Multi-axis Expansion
â–  ActiveX
® Programming Interfaces
â–  Motor Control I/O Port (Jogging, Interlocks)
â–  Seamless Software Integration with apt™ Family
ITEM#$£ ¥DESCRIPTION BSC101$1,351.50£795.00 1.192,50¥222,600Single Channel Stepper Motor Controller

Generic Motor Drive Breakout Board/Cable

Features

â–  2 Phase Stepper Motor Drive Cable
â–  3m Length
â–  Wide Range of Motors Supported
â–  Fully Labelled Connector Block A generic break out board/cable for use with our apt™ range of stepper motor controllers(including the new Opto Stepper Cube). Allows connection of the apt™ controllers to a wide range of new/legacy two phase stepper motors for easy and seamless control via the intuitiveapt™ user interface software. This break out board has a terminal block at one end containingclearly labelled easy connect terminals providing connection to the usual stepper motor lines such as phase A and B and encoder A and B.
ITEM#$£ ¥DESCRIPTION BOC101$153.00£90.00 135,00¥25,200Breakout Board/Cable For OST Stepper (OST001) BOC201$153.00£90.00 135,00¥25,200Breakout Board/Cable For BSC StepperBOC301$153.00£90.00 135,00¥25,200Breakout Board/Cable For MST Stepper (MST601) Sales: 973-579-7227
335
