Tools of the trade - Vol 18 - 36188 Performance™ Series Optical Breadboards – 2.4" Thick

Breadboards

Thorlabs Performance™ optical breadboards provide high performance at an economical price. A favorite of OEMs, these all steelbreadboards are also an ideal laboratory platform for optical and laser experiments.

Breadboard Supports

â–

Athermalized Design for Excellent Thermal Stability

Optical Tables

â–

Minimal Deflection Under Load

â–

Plated Steel Honeycomb Core & Internal Damping Provide Both Static and Dynamic Rigidity

Table Supports

â–

Magnetic Stainless Steel Top and Bottom Plate

â–

Excellent Surface Flatness, Achieved by Using a Single State of the Art Material and a Thermal Bonding Process

Non-Magnetic

PERFORMANCE SERIESBREADBOARDS

Specifications

â–

Flatness:

2

±0.13mm (0.005") over any0.3m area

â–

Thickness: (60mm) 2.4"

â–

Construction: Double-plate, singlehoneycomb-core, Athermalized Design

â–

Damping: Nominal

â–

Core: High Density Plated steelHoneycomb

â–

Top plate: Magnetic Stainless Steel, 5mm(3/16") thick, brush Finished

â–

Bottom Plate: Magnetic Stainless Steel,5mm (3/16") thick

â–

Sides: Black laminated steel

â–

Mounting Holes: Not sealed Rigid Support FrameSold Separately, See Page 34.

â–

Hole Spacing: • Imperial: 1â�„4"-20 on 1" centers • Metric: M6 on 25mm centers

â–

Edge of Top Plate to First Hole: • Imperial: 2" • Metric: 50mm Performance™Breadboards, 2.4" Thick - Stocked for Immediate Shipment

ITEM#$£ ¥DIMENSIONS PBH11101 $401.20 £236.00 354,00¥66,080 1' x 1' x 2.4" PBH11102$474.30£279.00 418,50¥78,120 2' x 1' x 2.4" PBH11122$559.30£329.00 493,50¥92,1202' x 1.5' x 2.4" PBH11105$644.30 £379.00 568,50¥106,120 2' x 2' x 2.4" PBH11110*$793.90 £467.00 700,50 ¥130,7602.5' x 2.5' x 2.4 PBH11103$596.70 £351.00 526,50¥98,2803' x 1' x 2.4" PBH11106* $775.20£456.00 684,00¥127,6803' x 2' x 2.4" PBH11111*$1,045.50 £615.00 922,50 ¥172,2003' x 2.5' x 2.4" PBH11114*$1,042.10 £613.00 919,50¥171,6403' x 3' x 2.4" PBH11107$938.40£552.00 828,00¥154,5604' x 2' x 2.4" PBH11112*$1,193.40 £702.00 1.053,00 ¥196,5604' x 2.5' x 2.4" PBH11115*$1,232.50 £725.00 1.087,50 ¥203,0004' x 3' x 2.4" PBH11113$1,343.00 £790.00 1.185,00 ¥221,2005' x 2.5' x 2.4" PBH11116$1,434.80 £844.00 1.266,00¥236,3205' x 3' x 2.4" PBH11117$1,679.60 £988.00 1.482,00 ¥276,6406' x 3' x 2.4"PBH11120$2,148.80 £1,264.00 1.896,00 ¥353,9206' x 4' x 2.4"

Performance™Breadboards, 2.4" Thick … Call for Lead Time

ITEM#$£ ¥DIMENSIONS PBH11104$690.20 £406.00 609,00¥113,6804' x 1' x 2.4" PBH11118$1,509.60 £888.00 1.332,00 ¥248,6404' x 4' x 2.4" PBH11108$1,093.10 £643.00 964,50 ¥180,0405' x 2' x 2.4" PBH11119$1,824.10 £1,073.00 1.609,50 ¥300,4405' x 4' x 2.4" PBH11109$1,213.80 £714.00 1.071,00 ¥199,9206' x 2' x 2.4"PBH11121$2,701.30 £1,589.00 2.383,50 ¥444,9208' x 4' x 2.4"
*These breadboards can be used with our ScienceDesk™ workstations. See pages 2-14 to learn more.Please contact your local sales office for a quotation including shipping.
