Tools of the trade - Vol 18 - 36188 Kinematic Breadboard & Joiner Plates

Translation StagesMotorized

â–

KJP601 – Mount theAPT600 Stage in aHorizontal Orientation or to Stack Several Stages Together

Mirror Mounts

KBB601KJP601

Rotation Stages3 Axis Flexure Stages

â–

KBB601 – Bolt ComponentsSuch as Fixtures or Camerasto the Side Faces

& Accessories 4, 5 & 6-Axis Stages Drive Electronics & Auto-Alignment Actuators & Adjusters

ITEM#METRIC ITEM$£ ¥DESCRIPTION KJP601KJP601/M$129.03 £75.90 113,85¥21,252 APT Kinematic Mounting and Joining Plate KJP601LKJP601L/M$129.03 £75.90 113,85¥21,252Left-handed Kinematic Mounting and Joining PlateKBB601KBB601/M$117.72 £69.25 103,88 ¥19,390APT Breadboard Plate

Fixed Bracket with Kinematic Seat

â–

Fixed Mounting Bracket forAPT600 Series Accessories

AMA609 â–

The AMA609 Attaches to theAPT600 Stage in Either Rightor Left-Hand Orientation

â–

Kinematic Base Plate Allowsfor Fast Exchange ofAccessories The AMA609 fixed angle bracket is designed to accept all of the APT600 seriesaccessories shown in this section. The hardened carbide steel guide pin and ball visible on the top of the platform serve to locate the accessories when they areplaced on the surface. A high strength rare earth magnet is used to hold theaccessory in place. The repeatability of this kinematic base design is better than ±2µm, reducing the time required to cycle through large number of devices in a manufacturing environment. The KJP601 joiner plate allows the APT600 stage to be mounted horizontally. It also allow the stages to be bolted together in a closestacked configuration. For horizontal mounting, thecorrectplate must be used to mate up with the face of the APT600 being fixed tothe mounting surface, either left or right hand. For close stacking, both the right and left hand plates are required.The KBB601 breadboard plates allow accessories such as fixtures, cameras and probes to be mounted to the side faces of the APT600 stage.

ITEM#$£ ¥DESCRIPTION AMA609$144.50£85.00 127,50¥23,800Fixed Bracket for APT600 Series Stage

Kinematic Base For APT600 Series Stages

â–

Kinematic Base Snaps into Placesfor Fast Exchange of Fixtures

â–

Mounting Holes Provided to AllowCustomer Supplied Devices to beAttached

â–  KMT601

Precision Register Points EnsuresLoad/Unload Repeatability of±2µm This blank kinematic base plate is provided to allow users of the APT600 series stages to quickly build their own device fixtures. Theright most photograph shows a series of precision machined grooves in the bottom of the plate. These grooves form a highly stablekinematic assembly when the plate is dropped into place on the stage. The rod and ball that are visible in the close-up photograph ofthe stage provide the mating features that create a series of register points for the top plate.

ITEM#$£ ¥DESCRIPTION KMT601$102.00£60.00 90,00¥16,800Kinematic Base for APT600 Series Stages
