Tools of the trade - Vol 18 - 36188 MicroBlock™ 4-Axis Device Platform, 62.5mm Deck Height

Translation StagesMotorized Mirror Mounts

Specifications

â–  Travel: θ y) 10°–Yaw Axis (
Pitch±5° Range Rotation Stages3 Axis Flexure Stages •Coarse Travel:–Horizontal Axis (x) 13mm –Vertical Axis (y) 6mm –Pitch Axis ( θ z) 10°•Fine Travel:–Horizontal Axis 300µm –Vertical Axis 300µm –Pitch Axis 30 arcmin. –Yaw Axis 30 arcmin.
& Accessories 4, 5 & 6-Axis Stages Drive Electronics Vertical6mm Range & Auto-Alignment Actuators & Adjusters â–  Resolution: •Coarse Travel:–Horizontal Axis 1µm –Vertical Axis 1µm –Pitch Axis 40 arcsec. –Yaw Axis 40 arcsec. •Fine Travel:–Horizontal Axis 50nm –Vertical Axis 50nm–Pitch Axis 2 arcsec. –Yaw Axis 2 arcsec.
Horizontal13mm Range MBT401 Patent 6,186,016 Deck Height62.5mm Yaw±5° Range â–  Deck Height: 62.5mm to themounting surface of the movingplatform. The accessory beam height is 75mm measured from the bottom surface of the stage. This MicroBlock™ Device Platform provides four degrees of freedom, twotranslation and two rotation. The 62.5mm deck height is compatible with our 3-Axis MicroBlock™, NanoMax™, and RollerBlock™ families of stages. Thephotograph below, shows the MBT401 4-Axis system integrated into a larger setupthat contains both a long travel RollerBlock stage, as well as a 4mm travel NanoMax 3-Axis flexure stage. We recommend this narrow platform positioning system for applications that require a device to bepositioned between two coupling stages. The extensive selection of accessories that are presented in the previous chapter (see page284), are all compatible with the platform stagespresented in this section.Given the large array of possible solutions toany particular alignment challenge, Thorlabs recommends that you contact one of ourregional offices for expert technical assistance inconfiguring a system that is ideally suited to your specific needs.
â–  Load Capacity: 500g (1.1 lbs)
â–  Weight: 1kg (2.2 lbs)
ITEM#METRIC ITEM #$£ ¥DESCRIPTION MBT401 MBT401/M$1,870.00£1,100.00 1.650,00¥308,000MicroBlock 4-Axis 62.5mmDeck Height Waveguide Manipulator Sales: 973-579-7227
