Tools of the trade - Vol 18 - 36188 Breadboards – Solid Aluminum

Breadboards

The imperial boards have a 1/2" border and four 1/4"-20 counterbored clearance holes. The larger boards have a 5th counterbored clearance hole in the center for added stability. The plates are machined from 1/2" thick solid aluminum plate for superior flatness specification.

Breadboard Supports Optical Tables

â–

Custom-Sizes Available

Table Supports

â–

Black Anodized

â–

Metric Boards AlsoManufactured&Stocked in EuropeThe metric boards have a 12.5mm border and four M6 counterbored clearance holes.The larger boards have a 5th counterbored clearance hole in the center for added stability. These boardsare machined from 12.5mm thick aluminum plates.Thorlabs now manufactures these boards in Europe as well, eliminating high shipping costs for our European customers.

SOLID ALUMINUMCONSTRUCTION!

Non-Magnetic

1/4"-20 Taps on 1" Centers; 1/2" Thick M6-1.0 Taps on 25.0mm Centers; 12.5mm Thick

ITEM#$£ ¥DESCRIPTION METRIC#$£ ¥DESCRIPTION MB4$52.00£39.00 58,50¥10,9204" x 6" MB1015/M$52.00£39.00 58,50¥10,920100 x 150mm MB4A$56.00£42.00 63,00¥11,7604.5" x 4.5" MB1111A/M$56.00£42.00 63,00¥11,760115 x 115mm MB6$58.00£43.50 65,30¥12,1806" x 6" MB1515/M$58.00£43.50 65,30¥12,180150 x 150mm MB624$178.84£105.20 157,80¥29,4566" x 24" MB1560/M$178.84£105.20 157,80¥29,456150 x 600mm MB636$236.30£139.00 208,50¥38,9206" x 36" MB1590/M$236.30£139.00 208,50¥38,920150 x 900mm MB648$293.93£172.90 259,40¥48,4126" x 48" MB15120/M$293.93£172.90 259,40¥48,412150 x 1200mm MB8$79.00£59.30 89,00¥16,6048" x 8" MB2020/M$79.00£59.30 89,00¥16,604200 x 200mm MB810$137.28£80.75 121,10¥22,6108" x 10" MB2025/M$137.28£80.75 121,10¥22,610200 x 250mm MB1012$158.27£93.10 139,70¥26,06810" x 12" MB2530/M$158.27£93.10 139,70¥26,068250 x 300mm MB12$169.58£99.75 149,60¥27,93012" x 12" MB3030/M$169.58£99.75 149,60¥27,930300 x 300mm MB1218$219.64£129.20 193,80¥36,17612" x 18" MB3045/M$219.64£129.20 193,80¥36,176300 x 450mm MB1224$297.16£174.80 262,30¥48,94412" x 24" MB3060/M$297.16£174.80 262,20¥48,944300 x 600mm MB1236$485.86£285.80 428,70¥80,02412" x 36" MB3090/M$485.86£285.80 428,70¥80,024300 x 900mm MB1248$581.23£341.90 512,90¥95,73212" x 48" MB30120/M$581.23£341.90 512,90¥95,732300 x 1200mm MB1824$403.75£237.50 356,30¥66,50018" x 24" MB4560/M$403.75£237.50 356,30¥66,500450 x 600mm MB2424$516.80£304.00 456,00¥85,92024" x 24" MB6060/M$516.80£304.00 456,00¥85,920600 x 600mm MB2436$663.00£390.00 585,00¥109,20024" x 36" MB2448$878.22£516.60 MB6090/M$663.00£390.00 585,00¥109,200600 x 900mmMB60120/M$878.22£516.60 774,90¥144,64824" x 48" 774,90¥144,648600 x 1200mm

SlimLine Breadboards – Double Density Hole Pattern

â–

Double DensityHole Pattern

Thorlabs now manufactures these boards inEurope as well,eliminating high shipping costs for our European customers.

â–

Custom Sizes Also Available

â–

Black Anodized Solid Aluminum Construction

â–

Metric Boards Also Manufactured &Stocked in Europe The new slim line series breadboards provide a double density 0.5"(12.5mm for metric version) offset hole pattern. This configurationmaximizes mounting versatility by doubling the number of tapped holes on the mounting surface. These boards are constructed of 1/2" thick aluminum plate to maintain flatness over the full length. The slim profile allows these boards to fit in compact areas. 1/4"-20 Taps on 1/2" Centers; 1/2" Thick M6-1.0 Taps on 12.5mm Centers; 12.5mm Thick

ITEM#$£ ¥DESCRIPTION METRIC#$£ ¥DESCRIPTION MB424$155.04£91.20 136,80¥25,5364" x 24" MB1060/M$155.04£91.20 136,80¥25,536100 x 600mm MB436$174.42£102.60 153,90¥28,7284" x 36" MB1090/M$174.42£102.60 153,90¥228,728100 x 900mm MB612$119.51£70.30 105,50¥19,6846" x 12" MB1530/M$119.51£70.30 105,50¥19,684150 x 300mm MB824$229.33£134.90 202,40¥37,7728" x 24"MB836$310.08£182.40 MB2060/M$229.33£134.90 202,40¥37,772200 x 600mmMB2090/M$310.08£182.40 273,60¥51,0728" x 36" 273,60¥51,072200 x 900mm

16
