Tools of the trade - Vol 18 - 36188 ScienceDesk™Breadboards, PerformancePlus™ Honeycomb

ScienceDesk™

Our PerformancePlus™ enhanced damped steel honeycomboptical breadboards are designed specifically for laboratory use. They combine all the features of the Performance™ breadboards discussed in the preceding page and offer enhanced damping, increased rigidity, and sealed mounting holes.

â–

Triple-plated double-core StableTop™ ConstructionSignificantly Increases Rigidity

BreadboardsBreadboard

â–

Enhanced Damping Improves Dynamic Performance for the most Critical Laboratory Applications

Supports

â–

Sealed Mounting Holes Make it Simple to Contain and Clean up Spills or Retrieve Lost Optics or Screws

Optical Tables Table Supports

Specifications

â–

Top and Bottom Plate:

Non-Magnetic

â–

Flatness: • Top plate: Magnetic StainlessSteel, 5mm (3/16") Thick, Brush finished• Bottom Plate: MagneticStainless Steel, 5mm (3/16") Thick

2

±0.10mm (0.004") Overany 0.3m area

â–

Thickness: 60mm (2.4") & 110mm(4.3") Versions

â–

Construction: Triple-plate,Double Honeycomb-core,Athermalized Design with Matching Plate Materials for Maximum Thermal Stability

â–

Sides: Black Laminated Steel

â–

Mounting Hole: • Imperial: 1â�„4"-20 on 1" Centers • Metric: M6 on 25mm Centers

â–

Damping: Enhanced

â–

Main Core: High Density PlatedSteel Honeycomb

â–

Edge of top Plate to First Hole:

â–

Intermediate Core: Plated SteelSealing Cup Honeycomb Structure,13mm (0.15") Thick. Cell Size Approximately 1.6cm • Imperial: 2"• Metric: 50mm

â–

Maximum Screw Depth: 16mm(5/8") from Breadboard Surface

2

(0.25 in.

2

) PerformancePlus Series ScienceDesk™Breadboards: Stocked for Immediate Delivery PerformancePlus Series ScienceDesk™Breadboards: Call for Lead Time

ITEM#$£ ¥DIMENSIONSCOMPATIBLE BASES PBI11110 $986.00 £580.00 870,00 ¥162,4002.5' x 2.5' x 2.4"Item #’s Ending 502, Page 3-6 PBI11106$1,014.90 £597.00 895,50 ¥167,1603' x 2' x 2.4"Item #’s Ending 501, Page 3-6 PBI11111 $1,307.30 £769.00 1.153,50¥215,3203' x 2.5' x 2.4"Item #’s Ending 503, Page 3-6 PBI11112 $1,485.80 £874.00 1.311,00 ¥244,7204' x 2.5' x 2.4"Item #’s Ending 504, Page 3-6 PBI11114 $1,349.80£794.00 1.191,00 ¥222,3203' x 3' x 2.4"Item #’s Ending 505, Page 3-6PBI11115 $1,574.20£926.00 1.389,00 ¥259,2804' x 3' x 2.4"Item #’s Ending 506, Page 3-6 ITEM#$£ ¥DIMENSIONSCOMPATIBLE BASES PBI12110 $1,018.30 £599.00 898,50¥167,7202.5' x 2.5' x 4.3"Item #’s Ending 502, Page 3-6 PBI12106$1,133.90£667.00 1.000,50 ¥186,7603' x 2' x 4.3"Item #’s Ending 501, Page 3-6 PBI12111 $1,343.00 £790.00 1.185,00 ¥221,2003' x 2.5' x 4.3"Item #’s Ending 503, Page 3-6 PBI12112 $1,524.90 £897.00 1.345,50 ¥251,1604' x 2.5' x 4.3"Item #’s Ending 504, Page 3-6 PBI12114 $1,411.00 £830.00 1.245,00 ¥232,4003' x 3' x 4.3"Item #’s Ending 505, Page 3-6PBI12115 $1,688.10 £993.00 1.489,50 ¥278,0404' x 3' x 4.3"Item #’s Ending 506, Page 3-6

Metric PerformancePlus Series ScienceDesk™Breadboards: Stocked for Immediate Delivery Metric PerformancePlus Series ScienceDesk™Breadboards: Call for Lead Time

ITEM#$£ ¥DIMENSIONSCOMPATIBLE BASES PBI51510 $986.00 £580.00 870,00 ¥162,400750 x 750 x 60mmItem #’s Ending 502, Page 3-6 PBI51506$1,011.50 £595.00 892,50 ¥166,600900 x 600 x 60mmItem #’s Ending 501, Page 3-6 PBI51511 $1,300.50 £765.00 1.147,50 ¥214,200900 x 750 x 60mmItem #’s Ending 503, Page 3-6 PBI51512 $1,480.70 £871.00 1.306,50 ¥243,8801200 x 750 x 60mmItem #’s Ending 504, Page 3-6 PBI51514 $1,343.00 £790.00 1.185,00 ¥221,200900 x 900 x 60mmItem #’s Ending 505, Page 3-6PBI51515 $1,565.70 £921.00 1.381,50 ¥257,8801200 x 900 x 60mmItem #’s Ending 506, Page 3-6 ITEM#$£ ¥DIMENSIONSCOMPATIBLE BASES PBI52510 $1,018.30 £599.00 898,50 ¥167,720750 x 750 x 110mmItem #’s Ending 502, Page 3-6 PBI52506$1,128.80 £664.00 996,00 ¥185,920900 x 600 x 110mmItem #’s Ending 501, Page 3-6 PBI52511 $1,334.50 £785.00 1.177,50¥219,800900 x 750 x 110mmItem #’s Ending 503, Page 3-6 PBI52512 $1,518.10 £893.00 1.339,50 ¥250,0401200 x 750 x 110mmItem #’s Ending 504, Page 3-6 PBI52514 $1,402.50 £825.00 1.237,50 ¥231,000900 x 900 x 110mmItem #’s Ending 505, Page 3-6PBI52515 $1,677.90 £987.00 1.480,50¥276,3601200 x 900 x 110mmItem #’s Ending 506, Page 3-6
Please contact your local sales office for a quotation including shipping.

Sales: 973-579-7227
