The C3A Swivel Coupler allows cage assemblies to be connected at angles rangingup to ±90°from the system normal. Made from stainless steel, these lockable couplers result in very rigid structures. Three-dimensional optical structures can be erectedusing the C1A couplers. These couplers can also be used to join two or more structures together.

Optical Rails Mirror Mounts

â–

180°Swing

Lens Mounts

â–

Ideal for Near Normal Angles

Filter MountsRotation

â–

Lockable

â–

Precision Ground Stainless Steel

Post Mounted Adapters V-MountsApertures

ITEM#$£ ¥DESCRIPTION C3A$89.00£66.75 93,45¥15,130Set of 4 Swivel End Connectors

C3A

& Iris Diaphragms

Tools of the trade - Vol 18 - 36188 Extension Rod Cross Couplers

Lens Tubes

NEW!

Cage Systems

BeamProfiler

C1A ER90A ITEM#$£ ¥DESCRIPTION C1A$18.00£13.50 18,90¥3,060Cross Rod Couplers

Swivel Coupler Rod End Swivel Connectors

See Page 798 â–

180°Swing

â–

Lockable

â–

Precision GroundStainless Steel These swivel couplers allow the connection ofcage assemblies at arbitrary angles. Made to close tolerances from stainless steel, these couplers canbe locked to provide an extremely rigid structure.

ITEM#$£ ¥ DESCRIPTION C2A$139.00£104.25 145,95¥23,630Set of 4 Swivel Couplers

Right Angle Rod & Spacer

Insert this right angle rod between two ER rods to form a “T” connectionpoint. To form a complete 90°cage assembly we recommend using the right angle rod spacer ER90A shown on the right.

30mm OverallLength EnsuresProper Separation ER90C â–

Maintains Perfect Rod Separationfor Cage Assemblies

â–

Build RigidStructures

â–

Increases Structural Rigidity WhenUsed with Inline Applications

â–

Ideal for StaticStructures Right Angle RodSpacer Rod

ITEM#$£ ¥DESCRIPTION ITEM#$£ ¥DESCRIPTION ER90C$11.00£8.25 11,55¥1,870 Right Angle Rod ER90A$5.10£3.82 5,36¥,867Right Angle Spacer Rod
