Optomechanics

Tools of the trade - Vol 18 - 36188 Lens Tube Construction Cubes

Mounting Basics

These building blocks are compatible with our SM1 and SM2-Series Lens Tubes found on pages 190-191.These precision machined components (square and parallel to better than 0.002") can be used in conjunction with our extensive line of SM1 and SM2 threaded components.

Optical Rails Mirror Mounts

â–

Compatible with the SM1 and SM2-series Lens Tubes

Lens Mounts

â–

Build Compact 3D Structures

â–

Easy Assembly of Extended Structures Using SM1 and SM2Threaded Components

Filter MountsRotation Post Mounted Adapters

Application Idea

V-MountsApertures

SM1C6

& Iris Diaphragms Lens Tubes Cage Systems

SM2C6 SM2C6 SM1C6SM1C6

SM1L30

ITEM#$£ ¥DESCRIPTION

Lens Tubes

SM1C6$20.00£15.00 21,00¥3,400SM1 Construction Cube SM2C6$39.00£29.25

See Page 189

40,95¥6,630SM2 Construction Cube

Right Angle Plate with Clear Aperture

These right angle plates with threaded clear apertures offer rigid mounting structures used directly within the beam path. Precisionmachining with the six surfaces from one solid extruded shape provides maximum rigidity, with parallelism and perpendicularity within 0.002" (0.05mm).

CAM1 CAM1

Application Idea

PR01 & CAM1

CAM2SM1 Threaded BoreSM2 ThreadedBore

Precision Rotation Stage See Page 164

CAM2 ITEM#METRIC ITEM#$£ ¥DESCRIPTION CAM1CAM1/M$89.00 £66.75 93,45¥15,130Right Angle Plate with 1.035"-40 Tapped Clear ApertureCAM2CAM2/M$89.00 £66.75 93,45¥15,130Right Angle Plate with 2.035"-40 Tapped Clear Aperture

Sales: 973-579-7227

195
