Tools of the trade - Vol 18 - 36188 ScienceDesk™Bases – Passive Vibration Isolation

ScienceDesk™ The Passive Isolation ScienceDesk frames are ideal for applications requiringa high degree of vibration isolation as long as the total weight of your equipment and breadboard is less than 180kg (400 lb). Above this weight threshold, better performance is achieved by selecting the heavy duty option on the preceding page. There are six size frames that accept breadboards from our Ultralight™, Performance™ and PerformancePlus™ breadboards. Many accessories are available to create a well laid out and ergonomic working environment (see pages 10-13).
BreadboardsBreadboard Supports Optical Tables Table Supports Non-Magnetic â–  Ergonomic Workplace Systems for Manufacturingand Scientific Research
Transmissibility (dB) â–  Modular Design
â–  Allows you to Customize your Workplace to Meet your Exact Needs
-50-40-30-20 -10010 â–  A Range of Adaptable Accessories to Customize the Working Area
101010 012 â–  Frequency (Hz) Heavy Duty Casters for Easy Movement
â–  ESD Safe with Grounding Kit (PSX105)
â–  Lightweight Aluminum Frame ScienceDesk ™ Transmissibility Plot
A variety of shelving modules for theScienceDesk are available on pages 10-11.

SPECIFICATIONS:

â–  Finish: Dark Grey
â–  Transmissibility(at 10Hz): ScienceDesk Bases-Passive
â–  Isolation Type: Passive
â–  Load Capacity (Including breadboard):
â–  Resonant Frequency: Vertical: <0.2dB (80%) Horizontal: <0.2dB (80%) 45 to 180kg (100 to 400 lbs) Vertical: <4.5HzHorizontal: <4.5Hz
â–  Frame Size: 195mm Deeperand Wider than the Work Surface Size
â–  Ergonomics: 415kPa (60psi) Maximum
â–  Transmissibility (at Resonance): In Accordance with BS527 and BS1335
â–  Air Pressure Required: Vertical: <9dBHorizontal: <9dB Leveling Feet: ±20mm (0.8")
â–  Height Adjustment Range:

ScienceDesk – themodular system designed to provide an ergonomic alternative to conventional workstations.

PSP501 Breadboardssold separatelyon pages 7-9 ScienceDesk Base – Passive Vibration Isolation: Stocked for Immediate DeliveryScienceDesk Bases – Passive Vibration Isolation: (Call for Lead Time)
ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSP503$1,997.50 £1,175.00 1.762,50 ¥329,000750 x 900mm (2.5' x 3') ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSP501$1,997.50 £1,175.00 1.762,50 ¥329,000600 x 900mm (2' x 3') PSP502$1,997.50 £1,175.00 1.762,50 ¥329,000 750 x 750mm (2.5' x 2.5') PSP504$1,997.50 £1,175.00 1.762,50 ¥329,000 750 x 1200mm (2.5' x 4') PSP505$1,997.50 £1,175.00 1.762,50 ¥329,000 900 x 900mm (3' x 3')PSP506$1,997.50 £1,175.00 1.762,50 ¥329,000900 x 1200mm (3' x 4') Please contact your local sales office for a quotation including shipping. Sales: 973-579-7227
