Tools of the trade - Vol 18 - 36188 ScienceDesk™ Bases – Passive Vibration Isolation, Heavy Duty

BreadboardsBreadboard Supports

â–

Ergonomic Workplace Systems forManufacturing and Research Environments

Optical Tables

â–

Modular Design

Table Supports

â–

Allows you to Customize your Workplace to Meet your Exact Needs Breadboardssold separatelyon pages 7-9 Breadboard modulesfor the ScienceDesk™available on pages 7-9

Non-Magnetic

â–  PSH501

A Range of Adaptable Accessories toCustomize the Working Area

â–

Heavy Duty Casters for Easy Movement

â–

ESD Safe with Grounding Kit (PSX105)

â–

Lightweight Aluminum Frame The Heavy Duty Passive Isolation frames are ideal ifyour application requires a high degree of vibration isolation, and the total weight of your application and breadboard exceeds 135kg (300 lbs). Below this weightthreshold, our standard Passive Isolation frames providebetter isolation; see the following page for more details. There are six size frames that accept select breadboards from our Ultralight™, Performance™ and PerformancePlus™ series breadboards. Many accessoriesare available to create a well laid out andergonomic working environment(see pages 10-13).

Transmissibility (dB) -40-30-20-10010 10 10 1 10 2 Frequency (Hertz)

ScienceDesk Transmissibility Plot ScienceDesk Base – Passive Vibration Isolation, Heavy Duty: Stocked for Immediate DeliveryScienceDesk Base – Passive Vibration Isolation, Heavy Duty: (Call for Lead Time)

SPECIFICATIONS:

â–

Height Adjustment Range:

â–

Transmissibility (at Resonance): ScienceDesk Bases-Passive Heavy Duty Leveling Feet: ±20mm (0.8") Vertical: <9dBHorizontal: <9dB

â–

Load Capacity (IncludingBreadboard):

â–

Finish: Dark Grey 135 to 540kg(300 to 1200 lbs)

â–

Isolation Type: Passive

â–

Transmissibility (at 10Hz):

â–

Resonant Frequency: Vertical: <0.2dB (80%) Horizontal: <0.2dB (80%)

â–

Frame size: 195mm Deeper andWider than the Work Surface Size Vertical: <6HzHorizontal: <6Hz

â–  â–

Air Pressure Required: Ergonomics: In Accordancewith BS527 and BS1335 415kPa (60psi) Maximum

ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSH504$2,057.00 £1,210.00 1.815,00¥338,800750 x 1200mm (2.5' x 4') ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSH501$2,057.00 £1,210.00 1.815,00¥338,800600 x 900mm (2' x 3') PSH502$2,057.00 £1,210.00 1.815,00¥338,800750 x 750mm (2.5' x 2.5') PSH503$2,057.00 £1,210.00 1.815,00¥338,800750 x 900mm (2.5' x 3') PSH505$2,057.00 £1,210.00 1.815,00¥338,800900 x 900mm (3' x 3')PSH506$2,057.00 £1,210.00 1.815,00¥338,800900 x 1200mm (3' x 4')
Please contact your local sales office for a quotation including shipping.
