Tools of the trade - Vol 18 - 36188 ScienceDesk™Bases – Active Self Leveling Vibration Isolation

ScienceDesk™ BreadboardsBreadboard Supports Optical Tables Table Supports Non-Magnetic Transmissibility (dB) -50-40-30-20-10010 101010 012 Frequency (Hz) ScienceDesk Transmissibility Plot See page 36 for an introduction to vibration theory. Select ‘Active Self Leveling’ over Passive or Rigid ScienceDesk frames when your application would benefit from automatic self leveling,while exceeding the high degree of isolation found in our Passive ScienceDesk frames. There are five standard size frames that accept selectbreadboards from three lines of our breadboards - Ultralight™, Performance, and PerformancePlus. This offers various levels of isolationto meet the needs of many applications. Many accessories are available to complete the design of a well laid out and ergonomic workingenvironment (see pages 10-13).
â–  Ergonomic Workplace Systems for Manufacturingand Scientific Research KeyboardHolder modulesfor the ScienceDesk available on page 12
â–  Modular Design
â–  Allows you to Customize your Workplace to Meet your Exact Needs
â–  A Range of Adaptable Accessories to Personalize the Working Area
â–  Heavy Duty Casters for Easy Installation
â–  ESD Safe when Used with Grounding Kit (PSX105)
â–  Lightweight Aluminum Frame

ScienceDesk – the modular system designed to provide an ergonomic alternative to conventional workstations.

SPECIFICATIONS:

â–  Height Adjustment Range:
â–  Transmissibility (at Resonance): ScienceDesk Bases-Active Leveling Feet: ±20mm (0.8") Vertical: <6dB Horizontal: <4dB
â–  Load Capacity (including Breadboard):
â–  Self Leveling Repeatability: 700kg (1545 lbs) ±0.25mm (0.010")
â–  Transmissibility:
â–  Frame size: 195mm Deeper and Widerthan the Work Surface Size
â–  Finish: Dark Grey Vertical (@5Hz): <0.05dB (95%) Horizontal (@ 10Hz): <0.002dB (99.8%) 690kPa (100 psi) Maximum
â–  Isolation Type: Active
â–  Air Pressure Required:
â–  Resonant Frequency:
â–  Ergonomics: Vertical: <1.6HzHorizontal: <1.2Hz In Accordance with BS527 and BS1335 Science Desk Base – Active Self Leveling Vibration Isolation: Stocked for Immediate DeliveryScience Desk Bases – Active Self Leveling Vibration Isolation: (Call for Lead Time)
ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSA503$2,975.00 £1,750.00 2.625,00 ¥490,000750 x 900mm (2.5' x 3') ITEM#$£ ¥ACCEPTS BREADBOARD SIZE PSA502$2,975.00 £1,750.00 2.625,00 ¥490,000750 x 750mm (2.5' x 2.5') PSA504$2,975.00 £1,750.00 2.625,00 ¥490,000750 x 1200mm (2.5' x 4') PSA505$3,060.00 £1,800.00 2.700,00 ¥504,000900 x 900mm (3' x 3')PSA506$3,060.00 £1,800.00 2.700,00 ¥504,000900 x 1200mm (3' x 4') Please contact your local sales office for a quotation including shipping. Sales: 973-579-7227
