Optomechanics Compact Kinematic Mount

Mounting Basics Mounting Basics

This compact mount features several upgrades.Increased thickness of the back plate enhances the stability of this general purpose mirror mount. Threaded brass sleeves for the adjusters ensure smooth long-term operation of the actuators; removable adjuster knobs provide a tamper-resistant feature; horizontal or vertical mounting allows this mount to be used as a prism mount or mirror mount. All these quality features are provided at a price that will satisfy even the most cost sensitive applications.

Optical Rails Optical Rails

Specifications

High Stability Features

Mirror Mounts Mirror Mounts

â–

Hardened Inserts Under AdjustmentScrews

KMS

Lens Mounts Lens Mounts

â–

Brass Sleeves for SmoothAdjuster Feel

Filter MountsRotation Filter MountsRotation

â–

3/16"-100 TPI Precision Adjusters

Remove knob fortamper resistant feature

Post Mounted Post Mounted Adapters Adapters

5/64" Hex Adjustersaccessible thru knobsFront Plate 1" x 1"

V-MountsApertures V-MountsApertures & Iris Diaphragms & Iris Diaphragms Lens Tubes Lens Tubes Cage Systems Cage Systems

ITEM#METRIC ITEM#$£ ¥DESCRIPTION MH25 KMSKMS/M$33.50£25.12 35,18¥5,695Compact Kinematic MountMH25*MH25*$9.50£7.12

ø

1" Mirror Holder up to 6mm thick 9,98¥1,615Mirror Holder for Ø1" Optics
*Imperial & Metric Compatible *Imperial & Metric Compatible

Fixed Mirror Holders

These fixed mirror holders provide an economical means of securing amirror in applications where a kinematic adjustment is not required. Ideal in applications where direction of the beam is controlled by other components.

Nylon-tippedlocking screw â–

Economical Mirror Mounting Solution

â–

Offered in both Imperial and Metric Versions

â–

Versions for

Ø1/2" (12.7mm), Ø

1" (

Ø

25mm) and

Ø

2" (

Ø

50mm)

â–

#8-32 (M4) Mounting Holes

FMP2FMP05FMP1

Motorized Mirror Mounts

ITEM#METRIC ITEM#$£ ¥DESCRIPTION FMP05FMP05/M$12.00£9.00 12,60¥2,040Ø1/2" Fixed Mirror Holder FMP1FMP1/M$14.00£10.50 14,70¥2,380Ø1" Fixed Mirror Holder FMP2FMP2/M$18.40£13.80 19,32¥3,128Ø2" Fixed Mirror Holder

See page 139

Right Angle Kinematic Cage Block

â–

Provide True 90°BeamSteering The KCB1 Right Angle Cage Plate hasbeen design to provide flexibility within a case system by providing a way to steara beam 90°. With two 100 TPIKinematic adjusters, the back plate of the KCB1 can be adjusted to provide a true 90°turn from one optic to the next.

â–

Accepts 1" Optics

â–

Compatible with 30mm Cage System

â–

Universal Design Provides#8-32 (M4) Taps forMounting

â–

Accepts SM1 Lens Tubes

KCB1 ITEM#$£ ¥DESCRIPTION KCB1*$100.00£75.00 105,00¥17,000Right Angle Kinematic Cage Block
