Tools of the trade - Vol 18 - 36188 Leveling foot, Horizontal Style

Mounting Basics

The horizontal style leveling foot bolts directly to the end of our XT95 structures.The threaded foot provides 30mm of adjustability for leveling assembled structures.

Optical Rails Mirror Mounts

â–

Heavy Duty Leveling Foot

Lens Mounts

â–

Supports Over 500lbs. per Sq. Foot

â–

30mm of Adjustability AllowsLarge Systems to be Leveled

Filter MountsRotation Post Mounted Adapters

ITEM#$£ ¥DESCRIPTION

V-MountsApertures

XT95P7$52.00£39.00 54,60¥8,840Horizontal Leveling Foot

& Iris Diaphragms

Optical Table Base Plate

Lens Tubes

The XT95P3 is an adapter plate that bolts ontothe end of our XT95 rails. This plate is intendedto connect the XT95 rail to either an English(1/4”-20) or Metric (M6) optical table.

Cage Systems

â–

Connects XT95 Rails Vertically to yourOptical Table

â–

Construct Extremely Rigid Structures overyour Optical Table

XT95P3

ITEM#$£ ¥DESCRIPTION XT95P3$27.00£20.25 28,35¥4,590XT95 Base Plate

Leveling Feet, Vertical Style

These leveling feet attach to the end of our XT95rail using four M6 screws. The threaded feet allow30mm of adjustment.

â–

Adjustable Leveling Feet Provide 30mm ofTravel

â–

Heavy Duty Stainless Steel Swivel Bases Provide Stability

XT95P5 XT95P5 ITEM#$£ ¥DESCRIPTION XT95P5$72.00£54.00 75,60¥12,240Vertical Leveling FootXT95P6$89.50£67.12 XT95P6 93,98¥15,215Dual Vertical Leveling Foot
