Nanolayers core expertise combines thinfilm optical coating of highest precision with ultra fast laser technology. Nanolayers ultra broad band GVD mirrors are the key component for Nanolayers lasers. The ultra fast lasers of Nanolayers generate the shortest pulses commercially available. Technical Specification

â–

Type: Passive external pumped ultrashort pulse laser

â–

Laser class: . . . . . . . . . . . . . . . . . . . 4 (EN 60825-1)

â–

Pulse width: . . . . . . . . . . . . . . . . . . . . . . . . . .

â–

Pulse energy: . . . . . . . . . . . . . . . . . . . . . . . . >= 2 nJ

â–

Pulse frequency: . . . . . . . . . . . . . . . . 80 - 200 MHz

â–

Average output power:. . . . . . . . . . . . >= 200 mW

â–

Bandwith (FWHM) . . . . . . . . . . . . . . . >= 150 nm

â–

Dimensions: . . . . . . . . . . . . . 550 x 350 x 150 mm

â–

Weight: . . . . . . . . . . . . . . . . . . . . . . . 32 kg / 80 Lbs VENTEON

Tools of the trade - Vol 18 - 36188 |

PULSE: ONE In cooperation with Professor F.X Kärtner and Professor J. G. Fujimoto from the Massacheusetts Institute ofTechnology, Nanolayers has developed the worlds fastest laser kit, the VENTEON

|

PULSE: ONE.Outstanding performance and ultra-compact size are hallmarks of the Nanolayers system. Basic Equipment | Components

â–

Ti:Sapphire Crystal

â–

9 GVD Mirrors | Custom Designed

â–

1 Output Coupler

â–

2 Optical Wedges

â–

Opto mechanical mounts and adjustablecomponents

â–

Adaption Optics for external Pump Laser ( Verdi | Millenia)

â–

Thermally stabilized Breadboard

â–

Aluminium transportation box The VENTEON

|

PULSE: ONEFemtosecond Laser.
