Tools of the trade - Vol 18 - 36188 XT34 & XT66 Double Dovetail Adapter Clamp

Mounting Basics

The XT66 and XT34 are complementaryrails for our XT Rail System. This adapter clamp provides a solution for integrating optical instruments built from these popular product families.

Optical Rails Mirror Mounts Lens Mounts XT34A6634mm to 66mm Adapter40mm(1.58") Length Filter MountsRotation

â–

Adapter Clamp for Integrating XT34 andXT66 Rail structures into One Setup.

Post Mounted

â–

Easy Access Side Clamping MechanismAllows Drop-On Access to ExistingStructures.

Adapters V-MountsApertures & Iris Diaphragms

ITEM#$£ ¥DESCRIPTION XT34A66$28.50£21.38 29,92¥4,845Double DovetailAdapter Clamp, XT34 to XT66

Lens Tubes

SOLDSEPARATELY SOLDSEPARATELY

Cage Systems

XT95 to XT66 Adapter Carriage

With the introduction of a 34mmlight duty and a 66mm mediumduty rail set along with our existing 95mm heavy duty rail, compatibility has become a key issue. While there are many ways tomount between rail systems, theXT95A66 Adapter Carriage forms an ideal link between these systems. The fixed adapter can be used to clamp two rails in parallel orreconfigured to clamp the rails perpendicular to each other.

XT66 ProfileXT95A66 XT34A66 XT95A66 XT95R66

â–

Adapter Clamp for Integrating XT66and XT95 Rail Structures.

XT95 Profile

â–

Adapter Plate can be Reconfiguredfor Perpendicular Rail Orientation.

ITEM#$£ ¥DESCRIPTION XT95A66$52.00£39.00 54,60¥8,840XT95 to XT66 Adapter Carriage

XT95 to XT66 Pivot Adapter

The XT95 to XT66 pivot adapter allows for 360°mounting of XT95 to XT66 rails. This versatility comes from taking advantage of the disc shaped dovetail adapter. This unique system makes itsimple to build complete optical assemblies on therigid XT95 support structure.

â–

360°Mounting Between the XT95and XT66 Rail Systems.

360°Rotation

ITEM#$£ ¥DESCRIPTION XT95R66$75.00£56.25 78,75¥12,750XT95 to XT66 Rotation Adapter
