Construction Cubes are Great General PurposeBuilding Blocks

V-MountsApertures

â–

Build Rigid 3-D Structures with these 1"Square Construction Cubes

& Iris Diaphragms Lens Tubes Cage Systems

METRIC ITEM#ITEM#$£ ¥ DESCRIPTION All 1/4"-20 (M6) TAPS RM1FRM1F/M$13.00£9.75 13,65¥2,2101"Construction Cube, Tapped Holes RM1G*RM1G*$12.75£9.56 13,39¥2,1681"Construction Cube, Clearance Holes SH25LP38—$21.00£15.75 22,05¥3,570Low Profile 1/4"-20 Channel Screws (100/box)—SH6M10LP$21.00£15.75 22,05¥3,570Low Profile M6 Screws (100/box)
* Universal Design Imperial and Metric Compatible.

“T” Nuts: Drop-in

XE25T1 1/4"-20 Tap (M6) â–

XE252T1 and XE25T2 Dropinto the Middle of ExistingStructures (No Need to Access Ends)

â–

1/4"-20 (M6) and #8-32 (M4) Taps

XE25T2

Low profile hex nuts can be used when you have access to the end of the extrusion toslip the nut into place. These are provided as a low cost alternative to our drop-in design. However please note that the XE25T3 hex nuts must be put into place prior to assembling your structure unless you have clear access to the end of the extrusion. The XE25T4 provides a quick and easy solutionfor inserting and locking a component onto an XE25-series rail. This “T” nut’s unique profileallows the “T” nut to drop in from the top ofthe rail and rotate 90°as a result of turning an #8-32 locking screw. Once the XE25T4 has completed its 90°rotation, the “T” nut will begin to translate upward until it locks inposition. This nut provides the sameconvenience during removal. The RM1G is designed to allow enclosures to bebuilt from our XE25 Structural Rails. We recommend the use of our low profile socket head cap screws detailed in the price box below; these screws provide enough clearance to allow 3 simultaneous connections as shown in the photograph to the right.The RM1F is machined from a solid block ofaluminum with all six sides held parallel to within ±0.002". Each face has a series of 1/4"-20 (M6) mounting holes. These components are ideal as general purpose building blocks that can be used with hundreds of our other mechanical products.

#8-32 (M4) XE25T3 1/4"-20 Tap (M6)

Sold 10per package Sold 10per package

ITEM#METRIC ITEM#$/PKG*£/PKG* /PKG*¥/PKG*DESCRIPTION XE25T1XE25T1/M$28.00£21.00 29,40¥4,760Drop-In 1/4"-20 (M6)T1 Nuts (Package of 10) XE25T2XE25T2/M$32.00£24.00 33,60¥5,440Drop-In #8-32 (M4)T2 Nuts (Package of 10)XE25T3XE25T3/M$8.50£6.38 8,93¥1,445Low Profile Nuts 1/4"-20 (M6) (Package of 10)
* Price per package of 10.

Quick Release Drop-In T-Nut

XE25T4 #8-32 (M4) â–

Unique design allows nut to drop into rail, then rotate intoa tightening position

â–

Release and removal from railsus just as easy as tightening

ITEM#METRIC ITEM#$/PKG*£/PKG* /PKG*¥/PKG*DESCRIPTION XE25T4XE25T4/M$34.00£25.50 35,70¥5,780Quick Release Drop-In XE25 T-Nut (Package of 10)
* Price per package of 10.
