Optomechanics

Tools of the trade - Vol 18 - 36188 Ø 1.5" Mounting Post Bracket

Mounting Basics

The C1505 fits anyØ1.5" post. The angle bracket provides an array of mounting options; four 1/4" (M6) clearance slots, seven 1/4"-20 (M6) mounting holes and two 1/4" (M6) clearance holes.

Optical Rails

C1505

Mirror Mounts Lens Mounts Filter MountsRotation Post Mounted Adapters

METRIC

V-MountsApertures

ITEM#ITEM#$£ ¥DESCRIPTION C1505C1505/M$90.00£67.50 94,50¥15,300Mounting Post Bracket

& Iris Diaphragms Lens Tubes

Ø 1.5" Adjustable Height Collar

Cage Systems

PSHA C1505 Fully Extended, 1.68" (43mm) Fully Retracted, 1.26" (32 mm ) PSHA

The PSHA Adjustable Height P-Post Collar offers a convenient height adjustmentfor post mounted hardware (see our C1500-series components). An easy-to-access actuator ring allows fine height adjustment at 0.025" (0.64mm) per revolution. Heavy Duty Design for Basic Research,Industrial R&D,and High Precision Manufacturing...

ITEM#$£ ¥DESCRIPTION PSHA$51.00£38.25 53,55¥8,670Adjustable Height Collar

Ø 1.5" Adjustable Platform

This manually-adjusted platform is intended forapplications that do not require the precision orflexibility of a laboratory jack. When locked, thisplatform provides a very stable 3" x 3" (75mm x75mm) work surface at a fraction of the cost of a lab jack.

Lab Jack

See Page 84

â–

1.5" (38mm) Vertical Range

1.5"(38mm)VerticalRange â–

Fits Any Ø1.5" Post

C1506

METRIC Post and Basesold separately ITEM#ITEM#$£ ¥DESCRIPTION See page 90 C1506C1506/M$89.00£66.75 93,45¥15,130Coarse AdjustableHeight Platform

Sales: 973-579-7227

95
