• Exercise care when handling the product. Dropping or tapping it may result in breakage.

• Do not disassemble the product unless it is unavoidable. Disassembling the product unnecessarily may result in the entry of foreign matter or cause accuracy degradation.

• Operating the product exceeding the permissible revolution speed may lead to part breakage or accidents. The operating revolution speed should be limited to the range specified by THK.

• Do not use the product at temperatures exceeding 80°C. Should it be required to use it at 80°C or higher, contact THK.

• To deliver the full extent of SKR-type functions, lubrication is essential. Use of the product without lubrication may result in increased abrasion at the rolling section or shorter life.

• Wipe the rust-preventive oil from the product sufficiently and then fill it with lubricant before use.

• Do not mix and use lubricants with different properties.

• The greasing intervals differ with the operating conditions. It is recommended that the greasing intervals be determined at the initial inspection.

• If the product is used in locations constantly exposed to vibration or in special environments such as clean rooms, vacuums, low temperatures, or high temperatures, there are cases where ordinary greases cannot be used. In such cases, contact THK.

• If locations are constantly exposed to vibration or in special environments such as clean rooms, vacuums, low temperatures, or high temperatures, consult THK.

There may be differences between products appearing in photographs and the actual product.

The appearance, specifications, and other information are subject to change without prior notice to improve reliability, function, etc. When deciding to adopt the product, contact us beforehand.

We have exercised great care in preparing this catalog, but it is still possible that there are misspellings, omissions of letters, etc. THK assumes no responsibility or liability for damage resulting from such errors possibly contained herein.
