Instrument Control Toolbox table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Times New Roman", serif; } .font1 { font:15.00pt "Times New Roman", serif; } .font2 { font:5.00pt "Trebuchet MS", sans-serif; } .font3 { font:7.00pt "Trebuchet MS", sans-serif; } .font4 { font:9.00pt "Trebuchet MS", sans-serif; } .font5 { font:10.00pt "Trebuchet MS", sans-serif; } .font6 { font:19.00pt "Trebuchet MS", sans-serif; } Simulink 3D Animation Animate and visualize Simulink models in three dimensions Overview Simulink 3D Animation™ provides an interface linking Simulink models and MATLAB algorithms to 3D graphies objects. It lets you visualize and verify dynamic system behavior in a virtual reality environment. Objects are represented in the Virtual Reality Modeling Language (VRML), an open 3D modeling standard. You can animate a 3D world by changing object properties such as position, rotation, and scale during desktop and real-time simulations. You can also access 3D animation data in Simulink or MATLAB for post-processing. Simulink 3D Animation includes a viewer for rendering and recording high-quality animations. With the 3D World Editor, you can author detailed scenes assembled from 3D models exported from CAD-based or Web-based sources. You can incorporate multiple 3D scene views inside MATLAB figures and interact with these views via a force-feedback joystick, space mouse, or other hardware device. Key Features ■ Simulink blocks and MATLAB functions for connecting models to virtual reality worlds ■ 3D World Editor for authoring 3D worlds ■ Video recording and animation playback ■ Visualization of real-time simulations ■ Client/server architecture ■ Interaction with 3D views via a joystick, space mouse, or other hardware device Visualization of Simulink based applications, clockwise from bottom left: self-balancing robot, aircraft over terrain, automotive vehicle dynamics, and wind farm. MathWorks- Accelerating the pace of engineering and science
