Compact conductivity/°C measuring instrument - With range of probes

testo 240

testo 240 is a complete conductivity measuring instrument and a high standard thermometer combined in one compact, waterproof housing.

Measurement errors caused by high conductivities and deposits on the electrodes are avoided thanks to the 4 electrode engineering used. The salt level (NaCI) in an aqueous solution can be measured directly.

» Long life of measurement cell thanks to 4 electrode engineering

»Extremely wide measurement ranges with only one measurement cell

Conductivity and temperature

measurement instrument in one

Versatile Set 1, Better value in set

testo 240 conductivity and temperature measuring instrument, battery, 2 electrode clips, versatile conductivity measurement cell, case (plastic)

Part no. 0563 2405

Measuring salt level (NaCI) in pickling brine

testo 240

Conductivity and temperature measuring instrument incl. battery and 2 electrode clips

Part no. 0560 2404

Precision Set 2, Better value in set

testo 240 conductivity and temperature measuring instrument, battery, 2 electrode clips, precision conductivity measurement cell, case (plastic)

Part no. 0563 2406


Technical data
Probe type	Conductivity measuring cell	NTC	Cale, parameter
Meas. range	0 to +2000 mS/cm	-50 to +150 °C	+1 to +200000 mg/l NaCI
Accuracy ±1 digit	±1% of mv (0 to +2000 mS/cm)	±0.5% of mv ±1.2% of mv (+1 to (+100 to +150 °C) +200000 mg/l NaCI) ±0.2 °C (-25 to +74.9 °C) ±0.4 °C (remaining range)
Resolution		0.1 °C	0.1 mg/l NaCI
Oper. temp.	0 to +40 °C	Dimensions	168x72x27 mm
Storage temp.	-20 to +70 °C	Weight	170 g
Battery life	60 h	Protection class	IP54


	Accessories Ordering data	Part no.
	Conductivity standard (1413 uS/cm), 0.01 mol/1 KCL, to calibrate conductivity measuring cells	0554 2334
	Set case (plastic) for measuring instrument, probes and accessories, user-friendly arrangement of measuring instrument and accessories	0516 0230
	ISO calibration certificate/analysis, for conductivity solutions; calibration point 1.413 mS/cm	0520 0019
	ISO calibration certificate/temperature, for air/immersion probes, calibration points -18°C; 0°C; +60°C	0520 0001
	ISO calibration certificate/analysis, at 3 conductivity values over the measuring range	0520 0049

Resolution max. 0.1 uS/cm; temperature compensation automatic; temperature coefficient: 0 to 5 %/°C linear; compensation in accordance with non-linear function of natural water to DIN 38404 from 0...+50°C; autom. measurement range switchover (conductivity); Auto OFF function; switch between °C/°F

Other features

Description

Illustration

Meas, range

Part no.

4 electrode 0650 3023

engineering with

built-in temperature ^Conn" ^Flxed ^cablesensor

+0.001 to +200 mS/cm

0 to +60 °C

Universal conductivity measuring cell, type 07 mS, highest accuracy up to 200 mS/cm, stainless steel

4 electrode engineering with built-in temperature sensor

+0.001 to +300 mS/cm

0 to +60 °C

0650 3024 Conn.: Fixed cable

Precision conductivity measuring cell, type 10 mS, long-term stable, highest accuracy up to 300 mS/cm, industrial graphite

Description Illustration Meas, range Accuracy t99 Part no.


	Waterproof NTC ^^^^^^^M immersion/penetration probe	115mm 50mm -50tO+150°C ±0.5% of mv (₊100 to _10s 06131212 r 0 5 mm 0 4 mm +125 °C, short-term ±04 °C (remaining range) oonn.. nxeu Oduie +150 °C (2 minutes)
	Laboratory probe, glass-coated, resistant to corrosive substances, *s_\|—=i— glass stem can be replaced	_?00mm 30 mm -50tO+150°C _±a5%ofmv(₊100to 40 s 0613 7011 -l I ) Long-term meas. range ₊₀._? °c *(-P5* to +74.9 °a ._ Conn ■ Trcd cable 0 6 mm 05 _mm +125 °C, short-term ±0.4 °C (remaining range) 10 oonn.. Mxea caoie +150 °C (2 minutes) S
	Stainless steel NTC food probe (IP65) with PUR cable	_125mm _15mm -50to+150°C ±o\|%ofmv(+iooto ₈s 06132211 0 4 mm 0 3 mm +125°C, short-term ±04 °C (remaining range) +150°C (2 minutes)
	Waterproof NTC surface probe for flat MOT*	_115mm 50mm -50tO+150°C ±0.5% of mv (+100 to 0613 1912
	surfaces	0 5 mm 0 6 mm +125 °C, short-term ±04 °C (remaining range) OOnn.: MXea caoie +150 °C (2 minutes)

See testo 110 for more temperature probes (except wireless probes)

* without protective glass
