38

Accessories for testo 175 and 177

testo 575 fast printer testo 580 data collector

•Fast-action print mechanism, 6lines/s•Prints tables/graphics•Brief info. or full memory can beprinted as required•Determine section to be printed•Your language can be set •Self-adhesive Testo paper canalso be used •Can read out up to 25 full testo175 loggers or 10 full testo 177loggers•Displays all status information •Download collected data to PCusing Testo ComSoft 3

Part no.testo 580 with RS232 interface0554 1778 Part no.0554 1775 Fast printout and logger rebooting withtesto 575 The testo 580 data collects data on sitefor upload to PC and analysis Part no.testo 580 with USB interface0554 1764

testo 581 alarm signal output Ethernet adapter

•Transmission of alarm messa-ges – e.g. when programmed limit values in the data logger are exceeded – to externalcomponents such as horns,lamps, PLC etc.•Signal transfer via floating signaloutput •Fast transfer of readings•Use of an existing network wi-thout additional cabling•Long transmission paths •Identification of measuring in-struments in system network•Used with ComSoft 3

Part no.0554 1769 Alarm signal output for reliable indicationof limits exceeded Part no.0554 1711 Read out data stored in the logger via thePC network using the Ethernet adapter Printer and Accessories Part no.Software and Accessories Part no. Part no.

Fast testo 575 printer, incl. 1 roll of thermal paper and batteries, infrared thermal line printer with graphics function For t testo 1 175: ComSoft 3 Set - Basic with RS 232 interface,Basic software with diagram and table function, incl. desk-top holder, PC connection cable

0554 1775 0554 1759

Spare thermal paper for printer (6 rolls)

0554 0569

For t testo 1 175: ComSoft 3 Set - Basic with USB interface, Basicsoftware with diagram and table function, incl. desk-top holders, PC connection cable

0554 1766

Spare thermal paper for printer (6 rolls), measurement data documentation legible for up to 10 years

0554 0568

For t testo 1 177: ComSoft 3 Set - Basic with RS 232 interface,Basic software with diagram and table function, incl. desk-top holder, PC connection cable Label thermal paper (Testo patent) for testo 575 printer (6 rolls), can be applied directly

0554 1774 0554 0561

For t testo 1 177: ComSoft 3 Set - Basic with USB interface, Basicsoftware with diagram and table function, incl. desk-top holders, PC connection cable

Further accessories Transport and ProtectionAccessories for humidity probes 0554 1767

testo 580 data collector set with RS232, readout holdersincluded, for testo 175/177 data loggers

0554 1778

ComSoft 3 - Professional with data management, incl.database, analysis and graphics function, data analysis, trend curve (without interface)

0554 0830

testo 580 data collector set with USB, readout holders included, for testo 175/177 data loggers

0554 1764

ComSoft 3 - For requirements to CFR 21 Part 11, incl. database, analysis and graphics function, data analysis, trend curve (w/o interface) testo 581 alarm signal output, floating, for testo 175/177, forwards information efficiently when limits are exceeded to e.g. horns, lamps, PLC etc.

0554 0821 0554 1769

RS232 interface for testo 175/177 incl. desk-top holders, PC connection cable, (please also order for ComSoft 3 - Professional)

0554 1757

Battery, 3.6 V/0.8 Ah 1/2 AA, for testo 175-T3/175-H1/175- H2/175-S1

0515 01750515 0177

USB interface, for testo 175/177 incl. desk-top holders, PC conn. cable, (Please order with ComSoft 3 - Professional) Battery, 3.6 V/1.9 Ah 1AA, for testo 175-T1/175-T2 and alltesto 177 loggers

0554 1768 Part no.

Ethernet adapter, RS232 - Ethernet incl. software driver, mainsunit, facilitates data communication in network

0554 1711

Lock for wall holder for testo 175/177 data loggers

0554 1755 Calibration CertificatesPart no.

Transport case for up to 5 testo 177 data loggers, testo 575printer, testo 580 data collector and accessories

0516 1770

ISO calibration certificate/temperature, temp. data logger; calibration points -18°C; 0°C; +60°C

0520 0151 Part no.

ISO calibration certificate/temperature, temp. data logger;calibration points -8°C; 0°C; +40°C testo saline pots for control and humidity adjustment of humidity probes, 11.3 %RH and 75.3 %RH with adapter for humidity probe

0520 0171 0554 0660

ISO cal. cert./humidity, humidity data logger; calibration points11.3%RH and 75.3%RH at +25°CDKD calibration certificate/temperature, temp. data logger; cal.points -20°C; 0°C; +60°C

0520 0076

Metal protection cage, Ø 12 mm for humidity probes, for measurement in flow velocities of less than 10 m/s

0554 0755

Cap with wire mesh filter, Ø 12 mm

0554 0757 0520 0261

Teflon sintered filter, Ø 12 mm, for corrosive substances, high humidity range (long-term measurements), high velocities

0554 0756

DKD calibration cert./humidity, humidity data logger; cal. points11.3%RH and 75.3%RH at +25°C

0520 0246

Stainless steel sintered cap, Ø 12 mm, is screwed onto humidity probe, for measurements at high flow velocities or in contaminated air

0554 0647
