Non-contact temperature measurement on large surfaces (10:1 optics)
testo 830-T1 testo 830-T4
The fast infrared thermometerwith 1-point laser sighting. The
10:1 optics are ideal for
temperature measurements onlarge surfaces The versatile infrared thermomterwith 30:1 optics allows
temperature measurement at a
safe distance from themeasurement object. Thediameter of the measurement
point at a distance of 1 m is only
3.6 cm. The 2-point laser sighting
avoids the measurement of
undesired areas outside the
measurement object. •10:1 optics•Display of current value andHold value•Emissivity adjustable from 0.2to 1.0•Audible and optical alarm whenlimit values are exceeded•Fast measurement valuerecording at two measurements
per second Additional benefits: •30:1 optics for measuringtemperature at a distance, even
on small objects•2-point laser for spot sighting
Large, backlit display Non-contact temperature monitoring on a pipe withtesto 830-T4. Two laser beams mark the measurement
point
testo 830-T4: Emissivitydetermination withexternal temperatureprobe
testo 830-T1 testo 830-T4 Set testo 830-T4
Infrared thermometer manufacturer with 1 point lasersighting, adjustable limit values andalarm function testo 830 T4, IR temperaturemeasuring instrument with 30:1 opticsand 2-point
laser measurement spotsighting, incl. battery and factory
calibration certificate with the meas.
points +80 °C and +350 °C testo 830-T4 set, consisting of testo830-T4 with protective leather case,incl. cross-band surface probe, batteryand factory calibration certificate with
the measurement points +80 °C and
+350 °C Part no.0560 8301 Part no.0560 8304 Part no.0563 8304 Technical data Common data testo 830-T4 Infrared thermometerContact measurement (Type K) Infrared thermometer Measuring rate0,5 s Meas. range-30 to+400 °C-50 to+500 °C -30 to+400 °C0.5 °C±1.5 °Cor1.5 % of mv(+0.1 to+400 °C)
±2 °Cor±2 % of mv(-30 to
0 °C)10:1 Oper. temp.-20 to+50 °C Accuracy±1 digit
at +23 °C ambienttemperature±1,5 °C(-20 to0 °C)±2 °C(-30 to-20,1 °C)±1 °Cor1% of mv
(remaining range)±0,5 °Cor0,5% of mv Storage temp.-40 to+70 °C EmissivityAdjustable 0.2 to1.0 Spectral range8 to 14 µm Resolution0,1 °C Battery type9V block battery Battery life15 h Dimensions190 x 75 x 38 mmOptical resolutionD:S30:1 (typical at a distance of 0.7 m to the measurementobject) 24 mm @ 700 mm (90 %) Accessories for testo 830-T1 and T4 Part no.
testo 830-T4testo 830-T1 Accessories for testo 830-T4 onlyPart no.
Industrial adhesive tape e.g. for polished surfaces (roll, 10 m long, 25mm wide), E = 0.95, temperature resistant up to +300°C 0554 0051
Fast-action surface probe with sprung thermocouple strip, also
for uneven surfaces, measurement range short-term to+500°C, TC Type K 0602 0393
Leather case to protect measuring instrument, including beltholder 0516 8302
ISO calibration certificate/temperature, meas. instr. with surface
probe; calibration points +60°C; +120°C; +180°C 0520 0071
ISO calibration certificate/temperature, infrared thermometer;
calibration points +60°C; +120°C; +180°C 0520 0002 testo 830-T1, 1 point laser sighting testo 830-T4, 2-point laser for spot sighting 10:1 standard optics 30:1 optics
Ø 16 mm Ø 18 mm Ø 24 mm Ø 36 mm Ø 68 mm Ø 100 mm 2000 mm 1500 mm 1000 mm 500 mm 700 mm 1 laser beam for spotsighting 500 mm1000 mm2000 mm5000 mm
Ø 516 mmØ 216 mmØ 116 mmØ 66 mmØ 16 mm
